0.7X-5X Industrial Electronic 3D Microscope Set - Full HD 4K Large Field of View

0.7X-5X Full HD 4K Large Field of View Industrial Electronic 3D Microscope Set

Overview

This industrial electronic 3D microscope set is designed for high-quality imaging and inspection. It features a 4K HD camera, 2D/3D lens, and 144 LED light source, making it ideal for various industrial applications.

4K HD Camera Specification:

• Sensor: IMX334
• Sensor size: 1/1.8
• Pixel size: 2.0*2.0μm
• Output resolution: 3840*2160
• Frame rate: 3840*2160@30FPS; 1920*1080@120FPS&60FPS
• Image storage method: TF card + UVC
• Video: 3840*2160@30FPS
• Exposure time: 0-33MS
• Exposure: Automatic and Manual
• White Balance: Auto and Manual
• Parameter settings: color, mirror, grid line, scale, etc.
• System software: Youngwin OS
• PC software: S-EYE2.0
• Working temperature: 0-60℃
• Storage temperature: -20-85℃
• Appearance size: 45.5*42*42mm
• Single machine weight: 0.11kg
• Power supply: DC 5-12V

2D/3D Lens Specification:

• Optical magnification: 0.7X-5.0X
• Working distance: 100 mm
• Eyepiece CTV: 0.4X
• Interface: Standard C interface
• 2D/3D stereo rotating viewer
• 2D/3D manual free switching
• The working distance remains the same when switching between 2D and 3D, no need to adjust the focus again
• 360° rotation, 45° objective lens angle

144 LED Light Source Specification:

• Input voltage: AC90V-240V
• Output voltage: DC12V
• Maximum output power: 5W
• Base material: plastic transparent cover
• Maximum inner diameter of lamp holder: 61MM
• Maximum outer diameter of lamp head: 94MM
• LED type: F3
• Number of LEDs: 144Pcs

Package Includes:

• 1 x 4K HD Camera
• 1 x Power cable
• 1 x C-mount Lens
• 1 x 3D view lens
• 1 x Focusing Bracket
• 1 x 144 LED Light Source

Summary of Key Features:

• High-quality 4K HD camera with 3840*2160 resolution
• 2D/3D lens with 0.7X-5.0X optical magnification
• 144 LED light source with adjustable brightness
• Supports TF card storage and UVC image storage method
• Compatible with Youngwin OS and S-EYE2.0 PC software
