150W 20A Battery Capacity Monitor Tester with 2.4-inch TFT Color Display and Adjustable Electronic Load

150W 20A Battery Capacity Monitor Tester Adjustable Electronic Load with 2.4-inch TFT Color Display

Product Overview

This electronic load is a direct current CNC electronic load with a maximum power of 150W and a maximum load current of 20A. It features a 2.4-inch TFT color screen that displays cumulative running time, core temperature with load, sensor monitoring temperature, voltage, current, power, electricity, capacity, internal resistance, load, operating mode, OVP, OCP, OPP, stop voltage, and time limit discharge.

Key Features:

• Four Working Modes: Constant current mode, constant voltage mode, constant power mode, and constant resistance mode
• Protection Features: Voltage, current, and power overrun protections can be set; stop discharge voltage and discharge time can be set
• Temperature Monitoring: Power-supplying temperature can be monitored by an external NTC sensor
• Multifunctional Design: System menu interface supports switching between English and Chinese, zeroing of accumulated data, zeroing of voltage and current at no load, voltage calibration and current calibration, 9 levels of screen brightness adjustment, standby time setting, and restoration of factory settings
• Advanced Safety Features:** **Protects first and then work mode to control the discharge, which can effectively protect the discharge power supply from damage caused by over-limit and over-discharge
• Precise Voltage Measurement:** **Adopts a four-wire wiring method, and the voltage measurement is not affected by the voltage drop of the wire, making the voltage measurement more accurate

Specifications:

• Name:** Electronic Numerically Controlled Load
• Material:** Printed circuit board
• Load Type:** CNC electronic load
• Working Voltage:** 12V DC with 12V, 1A power adapter
• Load Voltage:** 0~150V DC
• Load Current:** 0~20A
• Load Power:** 0~150W (Max. 60W above 120V)
• Wiring Method:** A+ V+ V- A- four-wire system, backward compatible with the two-wire system
• Maximum Power Measurement:** 999.999Wh
• Maximum Capacity Measurement:** 999.999Ah
• Cumulative Timing Range:** ddd:hh:mm: ss (days:hours:minutes: seconds)
• Operating Modes:** Four modes: CC-constant current mode, CV-constant voltage mode, CP-constant power mode, CR-constant resistance mode
• Overvoltage Protection:** Supports up to 150V overvoltage protection
• Overcurrent Protection:** Supports up to 20A overcurrent protection
• Over-power Protection:** Supports up to 150W over-power protection
• Limited Voltage Discharge:** Also called low voltage protection, support, default unlimited voltage discharge, set according to your needs
• Time Limit Discharge:** Supports up to 99 hours: 59 minutes time limit discharge
• Heat Sink:** Alloy integrated silent (20±3dBA) heat sink Internal temperature 240°C automatic operation
• External Temperature Measurement:** Connect NTC 3950 10K 1% temperature sensor to measure and display temperature from 0-100°C
• Chinese and English Interface Switching:** Supported
• Zeroing of Total Data:** Supported
• Voltage and Current Nulling:** Supported
• Voltage Open Calibration:** Supported
• Current Open Calibration:** Supported
• Screen Brightness Adjustment:** Supported
• Screen Hibernation Standby Setting:** Supported
• PC Software Online:** Not supported
• Restore Factory Settings:** Supported
• Item Size:** 165*95*80mm
• Item Weight:** 400g
• Package Size:** 195*105*135mm

Package Includes:

• 1 x Electronic Load
• 1 x Adapter
• 2 x Clip Wire
