"AVerMedia Extremecap U3 4K HDMI USB HD Video 3.0 Video Capture Card for 1080P 60fps OBS Capturing & Gaming Live"

4K HDMI USB HD Video 3.0 Video Capture Card Compatible 1080P 60fps for OBS Capturing/Gaming Live

Features:

• It can capture a single HD HDMI-compatible video signal
• The recorded video signal can reach 1080p / 60Hz, HDMI-compatible input supports 4K / 30Hz
• Support MJPEG and YUY2
• Support UAC & UVC agreement, support 48 kHz PCM audio sampling rate
• Some win7 need to install the driver
• Compatible with Windows 7, 8, 8.1, 10 or later, Linux OS, Mac OS operating systems
• USB3.0, 300 ~ 350MB / s bandwidth, compatible with USB 2.0 (40MB / s bandwidth)
• Can automatically detect the input video format, and automatically adjust to the set output size and frame rate
• Can automatically detect the input audio format and convert it to 48KHz PCM audio
• 2 collection rods can be used on a PC
• Support online firmware upgrades to better improve product compatibility
• The picture quality is clearer, the RGB color range is 0 ~ 255, and the delay is better
• Support all third-party player software compatible with UVC and UAC protocols
• System Requirements: Windows 10 / Windows 8.1 / Windows 7 (SP1)

Computer system requirements:

• Desktop computer: Intel Core i5-4440 3.10 GHz + NVIDIA GeForce GTX 660 or above
• Notebook: Intel Core i7-4810MQ + NVIDIA GeForce GTX 870M or above
• 4 GB RAM (8 GB recommended)

Mobile phone system requirements:

• Android phone (supported by newer phones):
• Only supports USB2, not USB3. (The reason is that the android UVC driver does not support USB3)
• If it is a USB Android phone, you need to force the pure USB2 cable into the USB2 mode to use

Specification:

• Input interface: 1 HDMI-compatible interface
• Output interface: USB3.0, 300 ~ 350MB / s throughput
• HDMI-compatible input: 4K / 30Hz, 1080P / 60, 59.94, 50, 30, 29.97, 25, 24, 23.98, 1080i 50/60, 720P 50 / 60,480P, 576P1280x1024, 1280x960, 1024x768, 800x600, 640x480
• HDMI-compatible sound input: LPCM sound signal
• HDMI-compatible input format: compatible with HDMI-compatible 1.4 standard, maximum bandwidth support 225MHz 4K / 30Hz, 12bit deep color
• Output format resolutions: 640x480 / 720x480 / 720x576 / 800x600 / 1024x768 / 1280x720 / 1280x960 / 1280x1024 / 1366x768 / 1360x768 / 1440x900 / 1400x900 / 1680x1050 / 1920x1080 frame rate: 25 / 29.97 / 30/50 / 59.94 / 60 fps;
• Video sampling rate: HDMI-compatible: 165MHz
• Audio and video capture: it conforms to UVC (USB video class) and UAC (USB audio class) standards
• Output color space: YUV, RGB
• Support operating system: Windows 7, 8, 8.1, 10 or later, Linux OS, Mac OS
• Power consumption: <= 2.5W
• Working temperature: 0-70 degrees Celsius
• Storage temperature: -20-120 degrees Celsius
• Storage humidity: 5% -90%

Software compatibility:

• Adobe Flash Media Live Encoder (Windows, OS X);
• Real Producer Plus (Windows); VLC (Windows, OS X, Linux);
• QuickTime Broadcaster (OS X); QuickTime Player (OS X), OBS, PotPlayer and etc.

Interface Description:

• Signal indicator: When the device captures video normally, the indicator lights up
• Power indicator: When the device is connected to the USB port of the computer, this indicator lights
• HDMI-compatible input: This slot is where the HDMI-compatible output source such as camera, camcorder, game box, IPTV box, etc. is connected
• USB3.0 output: This slot is where you connect the USB3.0 input of a computer or laptop

Package includes:

• 1 x Video Capture Card

Summary:**

This 4K HDMI USB HD Video Capture Card is a high-performance video capture card that can capture 4K / 30Hz and 1080P / 60Hz video signals. It supports MJPEG and YUY2, and is compatible with Windows, Linux, and Mac OS operating systems. The card also supports online firmware upgrades and has a low power consumption of <= 2.5W.
