Atten ST-3150D Intelligent IoT High-Frequency Digital Display Soldering Station - Mobile Phone Repair

Atten ST-3150D Intelligent IoT High-Frequency Digital Display Soldering Station for Mobile Phone Repair

Features:

• High-frequency eddy current heating, intelligent distribution of output power, with a maximum power of no less than 150W (High-Power Soldering)
• Pre-sensor design, fast temperature return, and precise temperature (Accurate Temperature Control)
• Three sets of fast temperature settings to meet the process parameters of different products (Customizable Temperature Settings)
• The infrared one-click temperature calibration function facilitates daily temperature inspection on the production line (Easy Temperature Calibration)
• Password protection function and button locking function (Enhanced Security)
• Intelligent standby and shutdown functions, extending the lifespan of consumables and saving energy (Energy Efficient)
• Ultrafine silicone handle wire, anti-scalding and anti-folding, long-lasting use without fatigue (Ergonomic Design)
• Real-time monitoring of ESD grounding function and ESD abnormal prompt function (ESD Protection)
• Plug and unplug the heating element for easy replacement (Easy Maintenance)
• Shelf silicone rubber ring, anti-knock, more secure (Secure Design)
• High and low-temperature alarm function, welding quality (Temperature Alert)
• The maximum temperature can be set to 600 degrees to meet the special applications of customers (High-Temperature Capability)

Specification:

• Model: ST-3150D
• Voltage: AC 110V/220V
• Power: 150W
• Temperature range: 80℃~600℃
• Temperature stability: ±2℃ (static without load)
• Heating core: HS-3150H
• Heating method: High-frequency eddy current heating
• Handle model: SP-H150
• Resistance of soldering iron head to the ground: <2Ω
• Solder head-to-ground voltage: <2mV
• Size: 195*124*124mm
• Note: ST-3150D with communication interface

Package includes:

• 1 x Soldering Station
• 1 x Soldering Iron Handle
• 1 x Soldering Iron holder
• 1 x Power Cord
• 1 x Copper Ball
