CXG 378 80W Semi-automatic Foot-operated Soldering Machine with Digital Display

CXG 378 80W Foot-operated Semi-automatic Digital Display Soldering Tin Machine

Product Overview

The CXG 378 automatic tin-feeding and welding machine is designed for continuous welding work, offering a semi-automatic welding effect and high work efficiency. It features a high-precision stepping motor, adjustable tin-feeding length, and multi-angle welding adjustment.

Key Features:

• Convenient and Efficient: Adjust the tin-feeding speed and length according to different welding needs, achieving a semi-automatic welding effect and high work efficiency.
• Precise Control: Precisely control the length and speed of tin delivery, ensuring the same solder joint size, reducing waste of tin wire, and saving 17% tin wire compared to manual.
• High-Quality Display: Double-row four-digit LED large screen white light display shows soldering iron temperature, tin feeding length, tin feeding speed, manual and automatic modes.
• Metal Anti-Static Design: Ensures safe welding of sensitive components, with higher efficiency, lightness, and flexibility.
• Versatile Applications: Suitable for various types of electronic connectors, LED string lights, video and audio cable plugs, headphone cables, computer data cables, small circuit boards, and small electronic components.
• Manual Internal Heating Type Soldering Iron: Easy to operate and simple, effectively improving work efficiency and saving resources.

Summary:

This CXG 378 soldering machine offers a convenient and efficient welding experience, precise control over tin delivery, high-quality display, metal anti-static design, versatile applications, and a manual internal heating type soldering iron.

Specification:

• Soldering Station:
• Model: CXG 378
• Power: 80W
• Temperature mode: ℃/°F
• Temperature range: 80~500℃/176~932°F
• Input voltage: AC100V/220V
• Suitable for tin wire diameter: 0.6, 0.8, 1.0, 1.2, 1.4, 1.6 (mm)
• Product size: 128*116*80mm
• Power cable length: 1.2M

• Soldering Iron:
• Model: CXG 901
• Soldering tips: 900M Series
• Resistance of soldering tip to the ground: ≦2Ω
• The voltage of soldering into the ground: ≦2mv
• Soldering iron cable length: 1.2M
• Soldering iron handle length: 220mm

Package Includes:

• 1 x Host
• 1 x Soldering Iron Handle
• 1 x Spring Soldering Iron Holder
• 1 x Foot Switch
• 1 x Universal Bracket
• 1 x Tin Feed Tube
• 1 x Tin Feed Spindle
• 1 x Power Cord
