DT-830B Portable LCD AC / DC Digital Multimeter for Voltage, Current and Resistance Measurement

DT-830B Portable LCD AC/DC Digital Multimeter

Features:

• 3 1/2 digits, 7-segment, 0.5-inch high LCD Display (Clear and Accurate Readings)
• Max display: 1999, Auto polarity display
• Small and compact design (Easy to Carry)
• Overload protection on all ranges (Safety First)
• Sampling 2~3 times readings per second
• Diode assembly test / Temperature test/Transistor hFE test (Multi-Functional)
• Low battery voltage indication
• It is easy to operate and the readings are indicated directly on the screen. It can be used to overhaul all kinds of circuit boards
• It is also an ideal teaching instrument for students

Specification:

• Model: DT-830B
• Max AC Current: 10A
• Max AC Voltage range: 1000V
• Max DC Voltage range: 750V
• Resistance Measurement range: 200Ω~2000KΩ
• DC voltage: 200mV/2000mV/20V/200V/1000V±(0.8%+2)
• AC voltage: 200V/750V±(1.2%+10)
• DC current: 2000uA/20mA/200mA/10A±(2%+2)
• Resistance: 200Ω/2000Ω/20kΩ/200kΩ/2000kΩ1000Ω±(1% + 2)
• Power Supply: 9V Battery (Not Included)
• Color: Black
• Size: Approx. 123*67*20mm

Package includes:

• 1 x Digital Multimeter(without battery)
• 2 x Test lines
