eMCP162 / 186 Programming Socket with USB Interface for Data Recovery

eMCP162 / 186 USB Interface eMCP Programming Socket for Data Recovery

Features:

• Also compatible with 186-FBGA 162-FBGA
• Shrapnel using imported beryllium copper by high-precision mold stamping, head-shaped imitation probe design, and later hardened, thickened gold-plated layer processing, thus ensuring product stability and durability
• Support hot-plugging and power switch alone, support through the USB interface or the cable and the board row of pins should be connected to the PIN for testing.
• Adopt floating board structure, accurate positioning, easy-to-pick and place IC, and higher work efficiency
• The test board is welded on the adapter board, the test holder does not need to be welded, and the pinhole can be inserted on the adapter board
• Product use: Programming holder, test holder, testing, reading, and writing of EMCP IC chips
• Package: EMCP162/186 with 0.5mm pin spacing.
• Test Stand: EMCP162/186-0.5
• Service life: 100000 times
• Summary: High-quality test socket with durable design, easy to use, and supports hot-plugging.

Specification:

• Model: EMCP162/186 test holder
• Pin spacing (mm): 0.5
• Number of Pins: 17
• Chip size: 12*18 / 14*18

Test method:

• Select the limit frame that matches the IC, and put the IC into the SOCKET according to the direction
• Plug the USB cable into the USB port on the computer, turn on the power switch of the holder, and select the corresponding test program

Package includes:

• 1 x Test Socket
