Fnirsi-5012H Portable Digital Oscilloscope: 500MS / s, 100MHz Analog Bandwidth

Fnirsi-5012H Portable Digital Oscilloscope
500MS/s Sampling Rate, 100MHz Analog Bandwidth

Overview
The Fnirsi-5012H is a portable digital oscilloscope designed for professionals and DIY enthusiasts. With its 100MHz analog bandwidth and 500MS/s sampling rate, it's perfect for a wide range of applications, from circuit debugging to signal analysis.

Key Features:

• **High-Speed Sampling**: 500MS/s real-time sampling rate for accurate signal capture
• **Wide Analog Bandwidth**: 100MHz analog bandwidth for capturing high-frequency signals
• **Advanced Triggering**: Single, Normal, and Auto trigger modes with ascending/descending edge triggering
• **High-Resolution Display**: 2.4-inch 320x240 display for clear waveform visualization
• **Long-Lasting Battery**: 3000mAh lithium battery for up to 5 hours of continuous use

Specifications:

• Analog band width: 100MHz
• Maximum real-time sampling rate: 500MS/s
• Vertical sensitivity: 50 mV/div ~ 100 V/div
• Horizontal time base range: 50S/div ~ 6nS/div
• Maximum test voltage: 80 V (1X probe), 800 V (10X probe)
• Storage depth: 128KB
• Input resistance: 1M
• ADC precision: 8bits
• Coupling mode: AC/DC
• Trigger mode: Single, Normal, Auto
• Trigger edge: Ascending/descending edge
• External trigger voltage 0-80 V
• Display: 2.4 inch - 320*240
• Power supply: 3000 mAh lithium battery
• Size: 114mm x 74mm x 33mm
• Weight: 250g

What's Included:

• 1 x FNIRSI-5012H oscilloscope host
• 1 x Matching 100MHz probe (1X and 10X)
• 1 x Micro USB data line
