Fnirsi DSO-TC3 Portable 3-in-1: Digital Oscilloscope, Transistor Tester, Signal Generator

Fnirsi DSO-TC3 Portable 3-in-1 Digital Oscilloscope & Transistor Tester & Signal Generator

Features:

• 3-in-1 functionality: digital oscilloscope, transistor tester, and signal generator
• **Automatically identify and measure various transistors, diodes, thyristors, and passive components**
• Oscilloscope with real-time sampling rate of 10MS/s, bandwidth of 500KHz, and maximum measurement of 400V voltage signal
• Signal generator with 6 signal waveforms: sine wave, square wave pulse wave, triangle wave, slope, DC
• Small and portable design with an invisible bracket for hands-free use
• Suitable for DIY learning, on-site commissioning, appliance repair, and power measurement
• 2.4-inch TFT color display with LED backlight for clear reading in strong light

Specification:

• Product Model: DSO-TC3
• Display: 2.4" TFT color screen with LED backlight
• Power supply voltage: Built-in 1500mAh rechargeable lithium battery
• Charging specification: USB Type-C 5V
• Product size: 79*103*31mm
• Real-time sampling rate: 10MSa/s
• Analogue bandwidth: 500Khz
• Input impedance: 1MΩ
• Coupling method: AC/DC
• Test voltage range: 400V
• Vertical sensitivity: 10mV-10V
• Horizontal time base range: 1us~10s
• Trigger mode: Automatic normal single
• Trigger type: rising edge/falling edge
• Waveform freeze: Yes
• Automatic measurement: Yes
• Triode: B greater than 10 less than 600
• Diode: Forward voltage drop <4.5V
• Regulator diode: 0.01~32V
• Field effect tube: JFET/IGBT/MIOSTET
• Unidirectional/Bi-directional SCRs: turn-on voltage <5V, gate trigger current <6mA
• Capacitance: 25pF~100mF
• Resistance: 0.010~50M2
• Inductance: 10uH~1000uH
• Battery: 0.1~4.5V
• Input voltage: 0~40V
• DS18B20: 0~85℃
• DHT1: 0~60℃/5~95%
• Infrared remote control decoding: NEC protocol infrared code
• Sine wave: 1~10KHz/0~3.3V/50%
• Square wave: 1~100KHz/3.3V/50%
• Pulse wave: 1~100KHz/3.3V/0~100%
• Triangle wave: 1~10KHz/0~3.3V/50%
• Ramp: 1~10KHz/0~3.3V/0~100%
• DC: 0~3.3V

Package includes:

• 1 x DSO-TC3 Tester
• 3 x Test Hook
• 1 x Regular Probe
• 1 x Type-C Cable
• 1 x P6100 High Voltage Probe (only Premium Edition)
