Fnirsi FNAC-28 Professional Grade Multi-function Type-C & USB Ripple Monitoring Tester

Fnirsi FNAC-28 Multi-function Type-C & USB Professional Grade Ripple Monitoring Tester

Features:

• Accurate Measurement:** 16-bit ADC chip for high-precision measurement
  Multi-function USB ammeter, bi-directional current, professional-grade ripple monitoring, USB-A/Type-C dual interface, super fast charging, plug and play, high measurement accuracy
• Dual Interface:** Supports different interfaces of charger detection and charging detection
  With USB-A, Type-C dual male port, suitable for different interfaces of the charger detection and charging detection, plug and play, no need to transfer
• Real-time Power Detection:** Bidirectional current charging, 6.5A high-current USB interface
  Real-time power detection bidirectional current charging, 6.5A high-current USB interface, straight-through charging power detection, Type-C interface supports bidirectional current output
• Fast Charging Protocol:** Supports various protocol triggers, covering mainstream fast charging protocols
  Fast charging protocol all-round king, supports a variety of protocol triggers, covering the mainstream fast charging protocols, adjustable output voltage, automatic detection, intelligent triggering, fast charging without worries
• Diversified Curve Detection:** Real-time voltage and current curve detection, D+D-voltage curve detection, high-speed voltage and current curve detection
  Diversified curve detection modes: real-time voltage and current curve detection; D+D-voltage curve detection; high-speed voltage and current curve detection
• Cable Detection:** Cable resistance detection, cable reading, analog testing, all-round protection of your charging safety
  Cable detection in one machine, cable resistance detection, cable reading, analog testing, all-round protection of your charging safety
• Data Records:** 5 groups of data records, power outage memory worry-free
  5 groups of data records, power outage memory worry-free, restart and continue to test without interruption, built-in battery capacity intelligent calculation, at any time to grasp the power state
• Additional Features:** Adjustable brightness, custom standby time, temperature symbol switching, language switching, analog DASH, analog Apple 2.4A, and more
  It fully features: adjustable brightness, custom standby time, temperature symbol switching, language switching, analog DASH, analog Apple 2.4A, and so on.
• Comprehensive Coverage:** All kinds of data cables, charging treasure, laptop charging test, and interface performance at a glance
  Comprehensive coverage of chargers, all kinds of data cables, charging treasure, laptop charging test, and interface performance at a glance

Specification:

• Model: FNAC-28
• Screen: 1.06 inch
• Monitor voltage: 4~24V 0.001V ±(0.2%+2)
• Monitor current: 0~6.5A 0.001A ±(0.2‰+2)
• Monitor power: 0~156W 0.001W ±(0.2‰+2)
• Detecting temperature: ℃, 1℃, ±(1.2%+3); °F, 1°F, ±(1.2%+4)
• Response time: 1 second
• Dimensions: 73*36*12mm
• Net Weight: 21g

Package includes:

• 1 x USB Tester
