Fnirsi SG-003A Adjustable Current & Voltage Simulator 0-10V, 4-20mA Signal Generator Calibrator

Fnirsi SG-003A 0-10V Adjustable Current Voltage Simulator 4-20mA Signal Generator Calibrator

Features:

• Expect the conventional signal input and output functions
• Voltage and current have automatic output functions, it can choose a single rise, three modes of a single drop, and cycle.
• With input-to-output conversion, voltage conversion active current mode, passive mode, and current conversion voltage mode
• The output has a custom function, the upper and lower output limits can be set arbitrarily
• Voltage input diagram, current input diagram, the frame rate is 10 frames
• PWM output can set frequency and duty cycle respectively
• Real-time curve: Real-time observation of changes in voltage and current
• It is powered by a large-capacity lithium battery and is charged with a Type-c interface (5V)
• The capacity of the lithium battery is 3000mHA, super long working hours
• The high-definition TFT color LCD screen makes the reading more eye-catching
• The resolution is 240*320, low power consumption, maximum power consumption: 0.32W
• Summary:** A versatile signal generator calibrator with advanced features and long battery life.

Technical Parameters:

• Active current output: Range: 0~24mA; Resolution: 0.01 mA; Maximum load: 750Ω; Precision: ±(0.1%+0.005)
• Passive current output: Range: 0-24 mA; Resolution: 0.01 mA; External power supply up to 30V; Precision: ±(0.1%+0.005)
• Voltage output: Range: 0-24 V; Resolution: 0.01V; Maximum current 30mA; Precision: ±(0.1%+0.005)
• 24V voltage output: Drive current: 24mA; Resolution: 0.01 mA; Precision:±(0.1%+0.005)
• Current input measurement: Range: 0-24 mA; Resolution: 0.01 mA; Input impedance: 100Ω; Precision: ±(0.1%+0.05)
• Voltage input measurement: Range: 0-30 V; Resolution: 0.01 V; Input impedance: 2MΩ; Precision: ±(0.1%+0.05)
• PWM output (frequency): Range: 0-9999Hz
• A single 3.7V 3000mAh lithium battery power supply; Standby time is 26 hours; the using time varies, based on the usage (It can be 8-10 hours with 20mA continuous output)
• Operating environment: 0°C - 50°C
• Internal reverse and overcurrent protection; Protection voltage: 30V
• Output automatically: Yes
• Size: 92*72*30mm
• Weight:165g

Package includes:

• 1 x Signal Generator Calibrator
• 4 x Test Clip
• 1 x Type-C Charging Cable
