GJ3C Smart-Fit Intelligent Tester with 0-320V Output and Voltage LED Backlight

GJ3C 0-320V Output Smart-Fit Voltage LED Backlight Intelligent Tester

Features:

• Light bead, light bar, backlight self-adaption test, avoid damaging light beads, the output voltage is 0~300V self-adaption, the output current is 1~30mA can be set (Automatically adjust voltage and current for safe testing)

• Intelligent identification of positive and negative poles of lamp bars, fast discrimination of polarity (Easy polarity detection)

• High and low voltage gear switches, all lamp beads can be safely tested (Multiple voltage settings for versatility)

• Test any LED single bead, strip, board, COB light source, etc (Universal compatibility)

• Can test any size LED TV backlight and other LED backlights without removing the screen (Convenient testing without disassembly)

• Can test the voltage parameters of various components, such as voltage regulator value, electrolytic capacitor withstand voltage value, etc (Multi-functional testing)

• Can test the voltage value of the DC power supply (within 300V) (Accurate voltage measurement)

• Adjust the brightness of lamp beads and boards under test (Customizable brightness control)

• Can test lamp beads, lamp boards, and circuit board leakage convenient for maintenance detection (Leakage detection for maintenance)

Specification:

• Input Voltage: AC 85~265V (International General)

• Output Voltage: DC 0~320V

• Output Current: 1mA/30mA

• Characteristic: 1mA/20V, 1mA/320V, 30mA/320V Three gears adjustable; No need to remove TV screen

Package includes:

• 1 x LED Tester

• 1 x Test Probes

• 1 x Power Cord
