Hantek 2C42 2-in-1 Handheld Digital Oscilloscope 40MHz + Multimeter Dual-Channels

Hantek 2C42 2-in-1 Dual-Channels 40MHz Bandwidth Handheld Digital Oscilloscope + Multimeter

Features:

• This all-new handheld oscilloscope is a 2-in-1 multifunction tester: oscilloscope and multimeter. Its sampling rate is 250MSa/s and its bandwidth is 40MHz (High-Speed Sampling)
• Support multi-angle adjustment, ultra-low-power, Type C charging interface, each 2-hour battery charge allows working one full day or standby for two months (Long-Lasting Battery Life)
• Output sine, square, triangle, trapezoidal, and other waveforms output (Multi-Waveform Output)
• 5V/2A large current or USB port of the ordinary computer can be charged, easy to use, and convenient with the Auto one-key test (Convenient Charging)
• Type-C charging interface, and standby for 2 months after every recharge of 2 hours with large capacity replaceable lithium batteries power supply (Long-Lasting Battery Life)
• Universal Multimeter Function: Test voltage, current, resistance, diode, capacitance, and continuity (Multi-Function Testing)
• Type C power + data transfer interface can share the charger and data cable with your mobile phone (Convenient Data Transfer)
• Small In Size & Held In Single Hand: The 45-degree suspension bracket design provides you with a workstation anywhere anytime (Portable Design)
• One Key Export Out & Quick Comparison: 2 groups of reference waveform + 6 groups of waveform storage, simple and effective (Easy Data Analysis)
• Digital Voltmeter Function: Automatic frequency and amplitude measurement, convenient to use and it supports Chinese & English menu display (Accurate Measurements)
• With Cursor Measurement Function: Supports time and voltage manual measurement, and measures the required waveform accurately (Precise Cursor Measurement)
• Color LCD Screen: Exquisite and smooth lines make the waveform clear and undistorted when magnified with a minimalist keyboard design simplifying operation (Clear Display)
• Unibody Casing: Fine touch feeling, favorable impact resistance, outstanding heat resistance, easy to disassemble (Durable Design)
• Self-Calibration Function: Free from level drift after a long time unused (Accurate Calibration)
• Scan Code for Video Help Function: Scan code on the back of the machine to get the help of online video help (Easy Video Assistance)

Specifications:

• Bandwidth: 40MHz
• Power Supply: AC 110~240V 50/60Hz
• Display: Full Color TFT LCD Display(320*240 pixels)
• Channel: 2CH + DMM
• Horizontal: Sampling Rate Range: 250MSa/s(Single-channel), 125MSa/s(Dual-channel)
• Waveform Interpolation: (sin x)/x
• Record Length: Max. 6K when single-channel, 3K each channel when dual-channel
• SEC/DIV Range: 5ns/div～500s/div 1, 2, 5 step-by-step
• Vertical: A/D Converter: 8-bit resolution, each channel sampled simultaneously; VOLTS/DIV Range 10mV/div～10V/divat input BNC; Bandwidth Limit, Typical: 20MHz
• Low Frequency Response (-3db): ≤10Hz at BNC
• Rise Time at BNC, Typical: ≤5ns
• Vertical Gain Accuracy: ±3% for Normal or Average acquisition mode
• Note: Bandwidth reduced to 6MHz when using a 1X probe.
• Power Supply: 2 * Built-in 3.7V 2600mAh Battery
• Product Size: 199 * 98 * 40mm
• Product Weight: 640g

Package includes:

• 1 x 2-in-1 Oscilloscope
• 1 x Clip Probe
• 1 x Test Probe
• 1 x Power Adapter
• 1 x USB Charging Cable
• 1 x Multimeter Probe
• 1 x Storage Bag
