Hantek 6022BE 20Mhz Dual Channel Laptop PC USB Digital Storage Virtual Oscilloscope

Hantek 6022BE Dual Channel 20Mhz Laptop PC USB Digital Storage Virtual Oscilloscope

Overview

This cost-effective virtual oscilloscope features an anodized aluminum casing, making it not only beautiful but also durable and wear-resistant. With a standard USB interface, it's easy to use and doesn't require an external power source.

Features

• Cost-effective and durable design with anodized aluminum casing
• Standard USB interface for easy use and no external power source required
• Suitable for notebook computers and product line maintenance, ideal for business use
• Compact and portable design, easy to carry around
• High performance with 48MS/s real-time sampling and 20MHz bandwidth
• Compatible with various operating systems, including Windows 7, 8, 10, NT, 2000, XP, and VISTA
• 23 measurement functions, including PASS/FAIL Check, suitable for technical applications
• Waveform average, persistence, intensity, invert, addition, subtraction, multiplication, division, and X-Y plot
• Save waveforms in various file formats, including text, jpg, BMP, MS Excel, and Word files
• FFT function available
• One computer can connect multiple DSO, easily extending channels
• Labview, VBVCDelphiC++Builder Second Design instance
• Summary:** Cost-effective, durable, and high-performance virtual oscilloscope with advanced features and compatibility.

Specification

• Channel: 2 Channels
• Bandwidth: 20MHz
• Input Impedance: 1MΩ 25pF
• Max. Sample rate: 48MS/s
• Vertical resolution: 8Bit
• Gain range: 20mV-5V, 8Steps
• DC accuracy: ±3%
• Timebase range: 1ns-9000s, 39 Steps
• Vertical adjustable: Yes
• Input protection: Diode clamping
• X-Y: Yes
• Trigger Mode: Auto, Normal and Single
• Trigger Slope: +/-
• Trigger level adjustable: Yes
• Trigger Type: Rising edge, falling edge
• Trigger Source: CH1, CH2
• Pre/Post trigger: 0-100%
• Sampling selection: Yes
• Waveform Display: port/line, waveform average, persistence, intensity
• Network: Open/Close
• Vertical mode: CH1, CH2, Dual, ADD
• Cursor measurement: Yes
• Math: FFT, addition, subtraction, multiplication, division
• Cursor: Frequency, Voltage
• Accessories: S/W CD, probes, manual, USB cord
• Operating system: Windows 7, Windows NT, Windows 2000, Windows XP, VISTA

Package includes

• 1 x Oscilloscope
• 1 x USB Cable
• 1 x CD
• 2 x Probes
• 1 x User Manual (in CD)
