HYELEC MY61 Digital Multimeter DMM with Capacitance and Transistor Test

Hyelec MY61 DMM Digital Multimeter w/ Capacitance & Transister Test

Features:

• Measurement type IV (CAT. IV), to use the entrance from repair port to power meter and the primary overcurrent protection device

• Measurement type III (CAT. III) is the measurement made within the building equipment.

• Note: For example, wiring of switchboard and circuit protector within fixed equipment includes cable, bus bar, junction box, switch, a socket output end, equipment for industrial purposes, and other equipment (such as permanently connected to the fixed motor of fixed equipment) for measurement.

• Measurement type II (CAT. II) is the measurement made on the circuit which is connected directly to low voltage equipment.

• Note: For example, measuring household equipment, portable instruments, and similar devices.

• Measurement type I (CAT. I) is the measurement made on the circuit which is not directly connected with the bus bar.

• Note: For example, the measurement which is not made on the circuit is not derived from the bus bar and special (internal) protection bus circuit. (For the latter, the instant overload varies, so the instant overload resistance of equipment must be marked.)

• When using this meter, the user should comply with the following standard safety procedures:

• The safety procedures to prevent electric shock

• The safety procedures to prevent wrong use

• To ensure your safety, please use the test probe provided with the meter. Before use, please check and make sure that it is intact.

Specifications：

• Summary:** Accurate and reliable measurements with high precision

• DC Voltage: 200mV/2V/20V/200V ±(0.5%+2) 1000V: ±(0.8%+2)

• AC Voltage: 200mV ±(1.2%+3) 2V/20V/200V ±(0.8%+3) 750V ±(1.2%+3)

• DC Current: 2mA/20mA/200mA ±(1.2%+3) 20A ±(2.0%+5)

• AC Current: 200μA/2mA/20mA/200mA ±(1.8%+5) 20A ±(3.0%+5)

• Resistance: 200Ω/2kΩ/20kΩ/200kΩ/2MΩ ±(0.8%+3) 20MΩ ±(1.0%+2) 200MΩ ±(6.0%+10)

• Capacitance: 2nF/20nF/200nF/2μF/20μF ±(4.0%+3) 200μF ±(6.0%+10)

• Display: 2000 Counts

• Data hold : √

• Diode test: √

• Transistor: √

• Continuity: √

• Auto power off: √

• Power: 9V (6F22) Battery (not included)

• Package size: 21 * 13 * 6cm / 8.3 * 5.1 * 2.4in

• Package weight: 508g / 1.1lb

Package list:

• 1 x HYELEC MY61 Auto Power Off DMM Digital Multimeter

• 1 x Test Lead

• 1 x English user manual
