InfiRay T3 384*288 1340M Night Vision Infrared Thermal Imager with USB Type-C Interface for Smartphone
0 out of 5 stars
No review yet| Qty | Price | Discount |
|---|---|---|
| 1 | NaN | |
| 3 | NaN | -3.3% |
| 5 | NaN | -4.9% |
| 10 | NaN | -7.4% |
Product details
Description
InfiRay T3 USB Type-C Interface 384*288 1340M Night Vision Infrared Thermal Imager for Smartphone
Key Features:
- High-Resolution Imaging:** 384×288 resolution, 17μm pixel pitch, and 19.5°×14.7° FOV for clear and detailed thermal images
- Accurate Temperature Measurement:** NETD ≤50mK@25℃，F#1.0, MRTD ≤400mK@25°℃，F#1.0, and temperature correction (manual/automatic)
- Real-Time Video:** 25Hz frame rate and digital detail enhancement for smooth and clear video playback
- Multi-Color Palette:** White-hot, black-hot, red-hot, and multiple palettes for customizable display options
- SDK Available:** Secondary development available for customized applications
- Compact and Lightweight:** Weighs less than 40g and measures 49.5×26×30mm for easy portability
Specifications:
- Model: T3
- Resolution: 384×288
- Pixel Pitch: 17μm
- FOV: 19.5°×14.7°
- Frame Rate: 25Hz
- NETD: ≤50mK@25℃，F#1.0
- MRTD: ≤400mK@25°℃，F#1.0
- Recommended Operating Temperature: -10℃+50℃
- Measurement Range: 0℃~+80℃
- Measurement Accuracy: ±3℃
- Temperature Correction: Manual/Automatic
- Power Consumption: <500mW
- Weight: <40g
- Dimensions: 49.5×26×30mm
- Supported OS: Android 6.0 and above
- Image Enhancement: Digital detail enhancement
- Image Correction: Manual
- Palette: White-hot/black-hot/red-hot/multiple palettes
- Secondary Development: SDK available
- Reticle: Reticle and hot spot tracking
- Video Storage: Photo and video storage
Package Includes:
- 1 x Infrared Thermal Imager
