JCID-D11 Multifunctional Intelligent Digital Detector for iPhone / Huawei: Measuring PCB Short Circuits

JCID-D11 Multifunctional Intelligent Digital Detector for iPhone/Huawei Measuring PCB Short Circuit

Features:

• **Summary: Intelligent Fault Detection in Seconds**
• D11 Digital Detector Enables Faults Detection In Seconds
• Bluetooth communication, intelligent acquisition of voltage and resistance to ground, help you to quickly analyze and lock faults
• Intelligent detection faster and more accurate, data acquisition, JC Drawing+D11, to create an intelligent maintenance ecology
• Multiple methods, to meet the needs of various, measurement scenarios
• Bluetooth Connection to JCID drawing software
• Measure the voltage, resistance, diode, short circuit
• Connect to Multimeter pen for manual measurement
• Connect to flex cable for automatic measurement
• A built-in rechargeable battery allows for repeated use
• Allow for Contrast and Analysis between the measured value and the standard value

Guidelines for usage (Ref.):

• Intelligent Measurement, Use: D11 + External measuring cable + Bluetooth receiver + JC drawing Mainboard
• Advantages: multi-channel simultaneous measuring, automatic recording, intelligent judgment, simple and efficient operation, getting rid of cumbersome
• Pen Measurement, Use: D11+Measuring pen Mainboard
• Advantages: Applicable to all equipment detection, detection of voltage, resistance, and diode value; with buzzer prompt; the touch pen automatically records data to the JC drawing platform
• External Panel Measurement, Use: D11+Measuring pen + External measuring panel + Measuring cable + Apple mainboard
• Advantages: Measuring the inline base no need to operate under the microscope, does not hurt the base, enlarging the test point for easy measurement

Package includes:

• 1 x Digital detector
• 1 x Multimeter pen
• 1 x External measurement flex cable(According to your choice)
