Jonsbo HF120 12cm Low Noise S-FDB Bearing Air Pressure Fan for Optimal Performance

Jonsbo HF120 12cm S-FDB Bearing Low Noise Performance Air Pressure Fan

Features:

• Ultra-Low Noise Performance: Jonsbo HF120 120mm high-performance fan with S-FDB long-life bearings

• High-Pressure Impeller Design: 9-blade impeller with curved sickle-shape low noise blades and magnetic stabilization system

• Multi-Point Dynamic Balancing: Sickle-shaped 9 blades for reduced vibration and noise

• High-Torque Motor: 16 levels of winding, high carbon steel shaft, and high torque for smooth start-up

• Shock Absorbing Feet: 2-stage shock absorbing feet with silicone pads to reduce operation resonance

• Smooth Operation: Copper bushing riveted to ensure smooth operation and stability of the shaft

• PWM Intelligent Speed Control: Speed range: 600-2000RPM (±10%)

Summary of Key Features:

• Ultra-Low Noise

• High-Pressure Performance

• Smooth Operation

Specification:

• Fan size: 120(L)*120W*25(H)mm

• Bearing form: S-FDB bearing

• Rated voltage: DC 10.8~13.2V

• Input current: 0.14±0.05A

• Voltage: DC 12V

• Starting voltage: ≥7V

• Speed: 600-2000rpm(±10%)

• Airflow: 14.98~65.5CFM

• Wind pressure: 0.21~2.63mm H2O

• MTTF: ≥30000 h Room Temp: 25°C

• Noise Level: 18.5~29.2dB(A)

• Interface: 1*4PIN

• Input Power: 1.68W

Package includes:

• 1 x Cooling Fan
