Jonsbo HX6200D 200W Radiator with AGRB Fan, 6 Heat Pipes, for Intel LGA 1700 and AMD AM4 CPU

Jonsbo HX6200D 6 Heat Pipes TDP 200W Radiator with AGRB Fan for Inter LGA 1700 and AMD AM4 CPU

Features:

• Compact and Powerful**: Jonsbo has developed a down-pressure radiator with a total height of 63mm HX6200D that adopts the powerful foundation of full reflow fins and copper bottom with 6 high-load heat pipes, and the TDP can still support up to 200W power consumption under the premise of ultra-small size to ensure compatibility
• With the addition of lighting attributes, it can meet the personalized needs of players in the personalized host
• Efficient Heat Dissipation**: 6 high-load heat pipes, heat pipes, fins, and bases, the full reflow soldering process conducts heat instantly and supports the powerful performance of the TDP200W tower radiator
• Compact Design**: The three-dimensional size is 63mm(H)*120mm(W)*120mm(L), which is only about 15mm higher than the motherboard 1/0, compatible with most ITX chassis
• Improve the heat dissipation of the power supply part, pass through the fin air duct, and reduce the temperature of the main board MOS tube and other heat-generating households
• Low Noise Fan**: 15mm thin fan with a lower noise value, under the premise of ensuring wind pressure penetration, the air volume is increased to 62CFM
• Each fan blade underwent dynamic balance adjustment twice, better vibration suppression, the noise is lower and smoother

Specification:

• Product name: HX6200D
• Product size: 63mm(H)*120mm(W)*120mm(L)
• Heatsink set size: 6Pcs
• Fan Size: 120mm(L)*120mm(W)*15mm(H)
• Speed of the Fan: 700-1800RPM
• Fan Air Volume: 13.1-62CFM
• Fan Noise: 18.6-29.7dBA
• Fan Air Pressure: 0.2-2.0mm H20
• Fan Rated Voltage: 7-12V
• MTTF: 50000h Toom Temp: 25℃
• Fan Rated Current: FAN 0.3A LED 0.23A
• Fan Power Consumption: FAN 3.6W LED 1.15W
• Fan Terminal: PWM 4PIN
• Scope of application: Intel 1700/1200/115X; AMD AM4
• Net Weight: 500g

Package includes:

• 1 x Radiator
