Jonsbo HX7280 Tower CPU Cooler - 7-Heatpipe Silent Air-cooled for Intel LGA 1700 & AMD AM4

Jonsbo HX7280 7-Heatpipe Silent Air-cooled Tower CPU Cooler for Intel LGA 1700 AMD AM4

Product Overview

The Jonsbo HX7280 is a high-performance CPU cooler designed for silent operation and efficient heat dissipation. With its advanced design and premium materials, it provides exceptional cooling performance for Intel and AMD platforms.

Key Features:

• Efficient Heat Dissipation: 56 layers of high-density fins provide a large 7459cm² cooling area for efficient heat dissipation.
• Silent Operation: Each fan blade undergoes two dynamic balance debugging for better vibration suppression, lower noise, and smoother operation.
• Flexible Fan Configuration: 2+1 fan matching for optimal cooling performance and compatibility with different memory heights.
• Wide Compatibility: Supports Intel and AMD high-end hardware platforms, including Intel LGA 115X/1200/2011/2066/1700 and AMD AM4.
• Reliable Construction: Avoids the problems of cracking and falling off of plastic fasteners, ensuring reliable operation.

Summary of Key Features:

Efficient heat dissipation, silent operation, flexible fan configuration, wide compatibility, and reliable construction make the Jonsbo HX7280 an ideal choice for CPU cooling.

Specifications:

• Product size: 140 * 155 * 160 mm
• Heatsink set size: 140*127*160mm
• Fan size: 140 * 140 * 25mm *2
• Fan size: 120 * 120 * 25mm *1
• Heat pipe specification: ∅6mmx7pcs
• Cooling power: 280W
• Fan speed (14cm): 700-1800RPM+10%
• Fan air volume (14cm): 34.57-90.2 CFM
• Fan air pressure (14cm): 0.46-2.74 mmH2
• Fan noise (14cm): ≤38 dbA
• Fan speed (speed reduction line 14cm): 1200RPM ± 10%
• Fan air volume (speed reduction line 14cm): 57.81 CFM (Max)
• Fan air pressure (speed reduction line 14cm): 1.14 mmH20 (Max)
• Fan noise (speed reduction line 14cm): ≤28dbA
• Fan speed (12cm): 700-1800RPM+10%
• Fan air volume (12cm): 32.47-83.04 CFM
• Fan air pressure (12cm): 0.47-2.68 mmH20
• Fan noise (12cm): ≤37.6dbA
• Fan speed (speed reduction line 12cm): 110ORPM+10%
• Fan air volume (speed reduction line 12cm): 45.56 CFM
• Fan air pressure (speed reduction line 12cm): 0.86 mmH20 (MAX)
• Fan noise (deceleration line 12cm): ≤28dbA
• Fan terminal: 4PIN PWM
• Bearing form: FDB Bearing
• Fan-rated voltage (14cm): 12V DC
• Fan-rated current (14cm): 0.21A
• Fan power consumption (14cm): 2.52W
• Fan-rated voltage (12cm): 12V DC
• Fan-rated current (12cm): 0.20A
• Fan power consumption (12cm): 2.4W
• Scope of application of CPU platform: Intel: LGA 115X/1200/2011/2066/1700; AMD: AM4

Package Includes:

• 1 x Cooler
