Jonsbo N4 Type-C 8-Bay Mini NAS Desktop Computer Chassis for ITX / MATX Motherboards

Jonsbo N4 Type-C 8 Hard Disk Mini NAS Desktop Computer Chassis Support ITX / MATX Motherboard

Product Overview

The Jonsbo N4 is a compact and feature-rich mini NAS desktop computer chassis designed for home office network storage, enterprise storage, and more. With its unique upper and lower compartment structure, this chassis supports MATX motherboards and half-height expansion cards, making it an ideal solution for a variety of applications.

Key Features:

• 8-Hard Drive Slots: Support for 8-disk hard drive installation with 2.5-inch disk space adaptable to SSD high-speed hard drive for extremely fast response.
• High-Speed Data Transmission: Front Type-C interface for high-speed data transmission.
• Server-Grade Hot-Swappable Backplanes: Adopt server-grade 10um gold-plated SAS hot-swappable interface to ensure a long service life.
• Compact and Easy to Install: Compact size of 286mm(W)*300mm(D)*228mm(H) with a removable one-piece top cover for easier installation.
• Multi-Disc Pull-Out Structure: With PCB adapter board, hot-swappable quick-replacement hard drives.
• Premium Materials: North American black walnut veneer made of 8mm thickness North American black walnut wood, solid wood, natural texture.
• Flexible Storage Options: Supports 8 disks, including 4 hot-swappable 3.5" disks on the left side for data exchange and 2 non-hot-swappable 3.5" and 2 non-hot-swappable 2.5" disks on the right side for local data storage.
• **Summary:** Ideal for home office network storage, enterprise storage, and more with its compact size, high-speed data transmission, and flexible storage options.

Specifications:

• Product Size: 286mm(W)*300mm(D)*228mm(H)
• Material quality: 0.7SGCC steel plate + black walnut wood
• Hard drive bays: 2.5" SSD *2; 3.5" HDD *6
• Compatible motherboards: ITX/M-ATX
• PCI Spreader Slot: 4 grooves
• Front interface: Type-C *1/UsB3.0 *1
• Power: SFX≤125mm
• CPU Cooler: ≤70mm
• Graphics card: support: ≤230mm
• Cooling System: 120mm*1(built-in)
• Weight: 3.75KG

Package Includes:

• 1 x Computer Chassis
