Kailiwei 0655EI 6X-55X Double Light Zoom Industrial Stereo Microscope for Phone Repair & BGA Welding

Kailiwei 0655EI 6X-55X Double Light Zoom Industrial Stereo Microscope for BGA Welding Phone Repair

Overview
This industrial stereo microscope is designed for BGA welding and phone repair, offering a total magnification range of 6X-55X and an extendable range of 0.22X-330X.

Features:

• Total Magnification:** 6X-55X (standard outfits)
• Extend total magnification: K0655 series: 0.22X-330X
• Zoom objective magnification: KH0655 series: 0.6X-5.5X, zoom ratio is 9.2:1. **Working Distance: 108mm**
• Trinocular/Binocular drawtubes horizontal inclined 35° and main body can be rotated 360°
• The range of adjusting the diopter: ±6
• Interpupillary distance adjustment range: 52mm-76mm (Left and right move at the same time)
• The range of adjusting the focus is 50mm (the square post is 100mm)

• Column aperture: Φ32mm
• Lens aperture: Φ76mm
• Center distance: 155mm
• Lifting range: 50mm

• Column height: 240mm
• Diameter: φ32mm
• Equipped with pressing tablet and Φ95mm black and white plate
• Base: 200*255*22mm

• 1 x Trinocular microscope head
• 2 x WF10X/20 Eyepieces
• 1 x Metal repair pad
• 1 x Focusing rack
• 2 x Eye-guards
• 1 x Dust cover
• 1 x Light
