Kaisi 3005D+ Adjustable Digital CNC DC Power Supply 30V 5A

Kaisi 3005D+ 30V/5A Adjustable Digital CNC DC Power Supply

Features:

• **High-Precision Power Control**: 30V/5A full digital power control single
• **Accurate and Reliable**: 10mV/1mA high accuracy and resolution, low noise and ripple
• **Multiple Protection Modes**: CV/CC given voltage and constant current mode, highly reliable OCP, OVP, arbitrarily set protection
• **Easy to Use**: Built-in set of parameters stored, outputs a switch control, power and memory function
• **Safe and Secure**: Keypad lock to prevent misuse, intelligent temperature control fan, effectively reduce the noise
• **Precise Voltage and Current Control**: 0-30V adjustable DC output high-precision, 10mV and 1mA resolution
• **Professional Power Supply Design**: Intuitive operability, simple and intuitive operation, fast and accurate selection of voltage and current can be realized
• **Additional Features**: To prevent damage to the load can be set to the value of over-voltage protection and over-current protection, keyguard lock panel buttons to prevent undesirable results in the key test engineering

Specification:

Operating Conditions:

• Input voltage: 220V / 110V
• Frequency range: 50- 60Hz
• Operating temperature : 32-104 ℉ (0-40 ºC)
• Operating humidity : < 80%RH
• Storage temperature : 32-158 ℉ (0-70 ºC)
• Storage humidity : < 70%RH

Stable Voltage:

• Output Voltage Range: 0-30V Continuously adjustable
• Setup Resolution : 10mV
• Setup Accuracy : <0.05% +20 mV
• Ripple : < 1mVRMS
• Read back Accuracy: 10 mV
• Temp. Coefficient : < 0.1% + 10mV
• Read back Temp. Coefficient : < 100 ppm+10mV

Stable Current:

• Output Current Range: 0-5A Continuously adjustable
• Setup Resolution : 1 mA
• Setup Accuracy : <0.1% +3mA
• Ripple : < 3mARMS
• Read back Accuracy: 1mA
• Temp. Coefficient : < 0.1% + 5mA
• Read back Temp. Coefficient : < 100 ppm+5mA

Package includes:

• 1 x Adjustable DC Power Supply
• 1 x Power line
