Korad KA6003P 60V 3A Adjustable Programmable DC Power Supply with USB & RS232 Interfaces

Korad KA6003P 60V 3A Adjustable Programmable DC Regulated Power Supply with USB RS232 Interfaces

Features:

• **High Accuracy and Resolution**: 10mV/1mA programmable power, low noise and ripple, CV / CC given voltage and constant current mode
• Output switch control, power, and memory function
• Keypad lock to prevent misuse, USB data storage, and automatic control functions
• Very Easy setup with a rapid adjustment knob
• The input voltage is switchable between 110/220 Volts for use in all countries
• It has 4 Memory Recall buttons so you can save time setting up the supply to your required conditions
• With a 0.001V and 0.001A resolution, 4 digits provide a more accurate and clearely visible readout for the voltage and current values with only 1 knob, extremely durable and easily visible even in low-light usage, meeting the needs of most people
• Grounding wire, thermal protection, voltage, and current overload, and short-circuit protection ensure the safety
• The built-in quiet variable fan reduces the operational noise and prolongs the life of the product
• There is a load on and off button so you can safely connect your load to the supply
• There is also a lock button to prevent accidental changes
• Easy to dial in the desired voltage with the encoded-controlled adjustment knob and then you choose the mode with one of the constant buttons
• USB & RS232 ports for remote control of the power supply

Specification:

• Input Voltage: AC 220V
• Voltage/current Range: 0-60V 0-3A Adjustable
• Load Regulation: Voltage: ≤0.01%+2mV; Current: ≤0.1%+5mA
• Line Regulation: Voltage: ≤0.01%+3mV; Current: ≤0.1%+3mA
• Setup Resolution: Voltage:10mV; Current:1mA
• Setup Accuracy (25°C±5°C): Voltage: ≤0.5%+30mV; Current: ≤0.5%+5mA
• Ripple(20hz-20m): Voltage: ≤1mV Rms; Current: ≤3mA Rms
• Temp. coefficient: Voltage: ≤100ppm; Current: ≤100ppm
• Read Back Accuracy: Voltage: 10mV; Current: 1mA
• Read Back Temp. coefficient: Voltage: ≤100ppm; Current: ≤100ppm
• Reaction Time (10%rated Load): Voltage: ≤100mS; Current: ≤100mS
• Operation Environment: Indoor Use
• Altitude: ≤2000m
• Working Temperature: 0°C~40°C
• Weight: 4.6kg
• Dimension: 110*156*260mm
• Storage Environment: Ambient Temperature: -10°C~70°C; Relative Humidity: ≤70%

Package includes:

• 1 x Power Supply
• 1 x Power Cable
• 1 x USB Line
