Korad KA6005D 60V 5A Precision Adjustable Digital DC Linear Power Supply Regulated

Korad KA6005D 60V / 5A Precision Adjustable Digital Control Regulated DC Linear Power Supply

Features:

• 60V/5A full digital power control single, 10mV/1mA high accuracy and resolution
• Low noise and ripple
• CV/CC given voltage and constant current mode
• Highly reliable OCP, OVP, arbitrarily set protection, keypad lock to prevent misuse
• Built-in set of parameters stored outputs a switch control, power, and memory function
• An intelligent temperature control fan effectively reduces the noise
• Simple and intuitive operation, fast and accurate selection of voltage and current can be realized
• It can be set to the value of over-voltage protection and over-current protection to prevent the voltage regulator from beyond the threshold
• The keyguard lock panel buttons prevent undesirable results in the key test engineering
• 5 user-programmable preset settings, press the button to recall and save area a key to bring up the user to store the data and save user settings
• Summary:** High accuracy and reliability, low noise and ripple, intelligent temperature control, and simple operation

Specification:

• Input voltage: 220V
• Operating temperature: 32~104℉ (0~40 ºC)
• Operating humidity: <80%RH
• Storage temperature: 32-158℉ (0-70 ºC)
• Storage humidity: <70%RH

Stable Voltage:

• Output Voltage Range: 0~60V Continuously adjustable
• Setup Resolution: 10mV
• Setup Accuracy: <0.05% +20mV
• Ripple: <1mVRMS
• Read back Accuracy: 10mV
• Temp. Coefficient: < 0.1% +10mV
• Read back, Temp. Coefficient: <100ppm+10mV
• Summary:** Accurate and stable voltage output with low ripple and high resolution

Stable Current:

• Output Current Range: 0~5A Continuously adjustable
• Setup Resolution: 1 mA
• Setup Accuracy: <0.1% +3mA
• Ripple: <3mARMS
• Read back Accuracy: 1mA
• Temp. Coefficient: <0.1% + 5mA
• Read back, Temp. Coefficient: <100ppm+5mA
• Summary:** Accurate and stable current output with low ripple and high resolution

Dimensions and Package:

• Dimensions: 110*156*310mm
• Package includes:
• 1 x Power Supply
• 1 x Test Line
• 1 x Power Cable
