LCR-TC1 Multifunctional Transistor Tester with 3.5-inch Colorful TFT Screen

LCR-TC1 3.5-inch Colorful TFT Screen Multifunctional Transistor Tester

Features:

• It can be widely used to detect NPN and PNP transistor, capacitor, resistor, diode, triode, N-channel, and P-channel MOSFET, IGBT, JFET, triac, and battery, etc
• One button operation automatically detects and shutdown, and you can press the multi-functional button to close the detector too
• Put the pins of the component in the corresponding area, then dial the little handle and the detector will test it automatically, finally, the results will display on the backlight TFT screen clearly
• It can also be used to detect infrared waveforms. It also can detect Zener diode and has the function of self-calibration
• **Summary:** Automatic multifunctional transistor tester with 3.5-inch colorful TFT screen, one button operation, and multiple detection functions

Specification:

• Display: 3.5 inches TFT Screen
• Diode Range: < 4.5V
• Zener Diode: Transistor Detect Area: 0.01 - 4.5V
• Zener Diode Detect Area: 0.01 - 30V
• Triac Range: IGT < 6mA
• Capacitance: 25pF - 100mF
• Resistor: 0.01 - 50MΩ
• Inductance: 0.01mH - 20H
• Battery: 0.1 - 4.5V
• Power Mode: Rechargeable Lithium Battery (include)
• Size: Approx. 90 * 50 * 25mm
• Color: White

Package includes:

• 1 x Transistor tester
• 3 x Test hooks
• 1 x Cable
