MaAnt R65 Sky Eye Trinocular Stereo Microscope 6.5-65X Synchronous Zoom with Aluminum Alloy Base

MaAnt R65 Sky Eye 6.5-65X Synchronous Zoom Trinocular Stereo Microscope with Aluminum Alloy Base

Product Overview

This MaAnt R65 trinocular stereo microscope offers unimaginably clear images, allowing you to mount a CCD camera and meet any job requirements with ease.

Key Features:

• Unparalleled Clarity**: High point wide-angle eyepiece adjustable, rotation adjustment factor 6.5~65X continuously adjustable
• Wide Field of View**: Large aperture wider field of view, hypervisual field, and double observation will not fatigue
• Precision Zoom**: 6.5-65 times, no power adjustment, fine-tuning knob by magnification, accurately grasp the required multiple, control the objective of 0.65-6.5 times to double
• High-Definition Optics**: High definition optical objective 6.5-65X optical zoom, large aperture, 18mm large lens, 4 layers of coating
• Bright and Energy-Efficient Lighting**: Dustproof mirror light source 26 strong LEDs, adjustable lamp bead, with LED light, adjustable brightness, knob adjustment, easy-to-operate
• Innovative CTV**: Innovate CTV, no shaking, no deformity, multi-directional performance improvement, to solve the image flat, reduce the distortion of the problem
• Adjustable Eyepiece**: The eyepiece diopter is adjustable, visibility is adjustable, the ocular tube has an adjustable diopter, and the pupil distance can be adjusted from 55-75mm
• 4K HD Camera Compatibility**: 4K HD camera, can be connected to CCD CMOS camera, can be matched with eagle CJ-1, eagle CJ-2, 4K high-definition industrial cameras
• Precision Measurement**: 4K precision measurement, three eyes synchronous HD display microcosm eye observation and screen display synchronous observation, picture clear and sharp detail

Specifications:

• Lens
  • Brand: MAANT
  • Model number: The Eye of Heaven R65
  • Optical magnification: 6.5-65X Continuously adjustable
  • Main objective magnification: 0.65X-6.5X
  • Zoom ratio: 1:10
  • Eyepiece magnification: WF10X/23 Adjustable large field eyepiece
  • Working distance: Approx.100mm
  • Port: Synchronous bayonet
• Support
  • Focusing mechanism: The focusing hand wheel is elastic and adjustable, and the lifting range is 50mm
  • Base column: The column height is 330mm
  • Floor size: 320*260*15mm
• Other Features
  • Viewing head: 45-degree tilt, hinged times
  • Interpupillary range: 52mm-75mm
  • Lighting mode: 26 Lamp bead LED adjustable light source
  • Net weight: 4.4kg
  • Product size: 380*320*260mm

What's in the Box:

• 1 x Microscope
• 1 x Focus Bracket
• 1 x Pillar
• 1 x Base
• 2 x Eyepiece
• 1 x Dustproof Lens
• 1 x 0.5X CTV Lens
• 1 x Ring Light
