Mechanic DT30P5 - 30V 5A Adjustable Intelligent DC Power Supply with 4-bit Digital Display

Mechanic DT30P5 30V5A Adjustable Intelligent Test DC Power Supply with 4-bit Digital Display

Product Overview

This Mechanic DT30P5 30V5A Adjustable Intelligent Test DC Power Supply is a high-quality power supply designed for precise voltage and current control. It features a 4-bit digital display for easy monitoring and adjustment of output voltage and current.

Key Features

• Adjustable Output Voltage and Current: 0-30V continuous adjustable output voltage and 0-5A continuously adjustable output current
• High Accuracy: Source effect and load effect less than 1 x 10^(-4)+3 mV, with a display error of less than 0.5%+ld
• Low Ripple Noise: Less than 1mV (RMS) ripple noise for stable output
• Fixed Output Option: 5V/2A fixed output option available
• Wide Input Range: 110V/220V+10% 60/50HZ input power supply

Specifications

• Mode: DT30P5
• Output voltage: 0-30V Continuous Adjustable
• Output current: Continuously adjustable 0-5A
• Source effect: Less than 1 x 10^(-4)+3 mV
• Load effect: Less than 1 x 10^(-4)+3 mV
• Ripple noise: Less than 1mV (RMS)
• Digital display: Two groups of 4-bit display
• Display error: Less than 0.5%+ld
• Fixed output: 5V/2A
• Output voltage: 0-30V
• Output current: 0-5A
• Source effect: Less than 5mV
• Load effect: Less than 15 ml
• Ripple noise: Less than 2mV (RMS)
• Input power supply: 110V/220V+10% 60/50HZ
• Size: 250 x 120 x 160 mm
• Weight: 4.5KG

Package Includes

• 1 x BST-305D host
• 1 x Power line
