Mechanic E3-B11 7X-60X Trinocular Stereo Zoom Microscope, Simul-Focal, B11 Big Base

Mechanic E3-B11 7X-60X Simul-Focal Trinocular Stereo Zoom Microscope with B11 Big Base

Product Overview

This Mechanic E3-B11 7X-60X Simul-Focal Trinocular Stereo Zoom Microscope is designed for precision and clarity. With its high-definition optical objective, precision craftsmanship, and high-definition coated objective lens, it provides a clear picture with no glare or neglect of details.

Key Features:

• High-Definition Optics: High-definition coated objective lens, pure copper lens barrel, no glare, clear picture with no neglect of details.
• Wide-Angle Eyepiece: Standard WF10X/25MM, wide-angle eyepiece with high eye point, easy to observe with eyeglasses. Summary: Easy observation with eyeglasses
• Adjustable Binocular Refraction: Adjustable diopter ±5DP for both eyes, easier binocular viewing.
• Continuous Zoom: 7-60X continuous zoom optical system, large magnification continuous zoom, sharp and undistorted images, very high clarity correct focusing. Summary: 7-60X continuous zoom
• Sharp Focusing: Focus knob, sharp details, focusing gear bar is made of metal, durable, with precise magnification, sharpens the image.
• CTV 2/5 Adapter: Sharper imaging than regular CTV interfaces, wider field of view, no dark corners.
• High-Definition Camera Display: Can be used with a 4K high-definition camera display, synchronized eye view with screen display, and large HD screen with no trail image.
• Large Working Distance: 120mm working distance, and 360° rotary adjustment, more room to operate. Summary: 120mm working distance
• Versatile Applications: Suitable for various applications, including mobile phone motherboard/circuit board/resistors, precision watches/inlaid crystals/micro-carved walnuts, tiny creatures/plants, teeth/glasses/ears, etc.

Specifications:

• Viewing Head: 45° tilt, 360°swivel, pupil distance 54-76mm bilateral vision adjustment +5 diopters
• Non-Adjustable Goggles: Standard configuration: WF10X25MM, high eye point wide angle type eyepiece; Provides convenience for observers wearing eyeglasses
• Optional Eyepieces: WF15X/15mm, WF20X/10mm, WF25X/9mm
• Objective: 0.7X-6X continuous zoom, objective zoom ratio 8.6:1
• Auxiliary Objective: 0.3X, 0.5X, 0.75X, 1X, 1.5X, 2X For option
• Magnifying Power: 7X-60X, optional eyepieces and auxiliary objectives can be extended to 3.5X-300X, continuous magnification
• Working Distance: 120mm
• Focusing Mechanism: A1 focusing bracket, handwheel adjustable, lift range 50mm
• Work Platform: 320*260mm
• Foundation: B11 Column Large Flat Base; Other base options available, see base series diagrams
• Trinocular Interface: With the trinocular rod and CTV can be connected to the camera, CCD
• Illumination: L65 LED ring lights

What's in the Box:

• 1 x Microscope Body
• 1 x Microscope Focusing Arm
• 1 x Goggles
• 2 x Eyepieces (WF10X/25)
• 1 x Dustproof Lens
• 1 x L65 Ring Light
• 1 x Smoke Exhaust Fan
• 1 x MCN CTV Adapter
• 1 x Limiter
• 1 x Base
