Mechanic Mic2 / Mic3 Binocular / Trinocular Stereo Microscope with B-11 Big Base

Mechanic Mic2 / Mic3 Binocular / Trinocular Stereo Microscope with B-11 Big Base

Features:

• High-Definition Viewing Experience: High field wide-angle eyepiece, explore, one step forward
• The Mic 3 microscope with standard WF10X/25MM high field wide-angle eyepiece, provides a wide and clear view, perfect for observing small objects like mobile phone motherboards, circuit boards, or chips.
• The high field of view design reduces eye fatigue caused by prolonged observation and is designed with the wearer's needs in mind.
• Advanced Coating Technology: The high-definition coated objective reduces light scattering and improves image contrast and clarity.
• The Mic 3 microscope features a variable magnification prism group, allowing for continuous zoom from 7X to 50X and accurate locking of the desired magnification.
• Ergonomic Design: The newly designed zoom handwheel features a comfortable non-slip silicone design, reducing fatigue from frequent use.
• Improved Imaging Effect: The Mic3 trinocular microscope with the CTV 0.45X adapter delivers sharper, more detailed images, eliminating the phenomenon of dark angle.
• Unprecedented Visual Experience: Combine the Mic3 trinocular microscope with a 4K Pro industrial-grade HD camera (not included) for an unparalleled visual experience.
• The combination allows for external HD display, synchronization of eye observation and screen display content, and high-definition large screen without shadow characteristics.
• Flexible Observation: 360° rotation allows for adjusting the microscope's viewing angle according to your needs.
• Adjustable Height: The Mic3 trinocular microscope has a lifting function, with a lifting range up to 100mm, allowing for comfortable viewing from various heights.

Specification:

• Non-adjustable eyepieces: WF 10X/25MM
• Zoom ratio: 1:7.1
• Optional eyepiece: WF10 X22MM / WF15 X15MM / WF20 X10MM
• Not adjustable eyepiece: Standard equipment: WF10X25; high-eyepoint wide-angle eyepiece for the convenience of spectacled observers
• Observation head: 45° inclination, 360° rotation, interpupillary distance 54~76mm bilateral vision adjustment±5 diopters
• Objective: 0.7X-5X continuous zoom, objective zoom ratio 1:7.1 to ensure image surface focus
• Auxiliary objective: 0.5X, 0.7X, 1.5X, 2X are available as options
• Magnification: 7X-50X, optional eyepiece, and auxiliary objective can be expanded to 3.5X-270X, continuous zoom
• Working distance: 100mm
• Focus bracket: The inner diameter is 76mm, and the column bore diameter is 32mm
• Work platform: 320*260mm
• Base: B11 column type large plate base, can be equipped with other bases see the base series diagram for details

Package includes:

• 1 x Microscope Head
• 1 x Microscope Frame
• 2 x WF10 X25MM Eyepiece
• 2 x Flat Angle Eye Mask
• 2 x Silicone Eye Mask
• 2 x Horn Eye Mask
• 1 x CTV 0.45X Adapter (only Mic3)
• 1 x Ring Light
• 1 x Column
• 1 x Limit Block
• 1 x B11 Base
