Mechanic Space X Series 6.5X-52X Trinocular Stereo Microscope for Continuous Zoom PCB Welding Repair

Mechanic Space X Series 6.5X-52X Continuous Zoom Trinocular Stereo Microscope for PCB Welding Repair

Overview:

This trinocular stereo microscope is designed for PCB welding repair, offering a wide range of features that enhance its performance and functionality.

Key Features:

• Advanced Optical Design: The microscope features a unique optical design that provides an ultra-clear image, reducing image edge distortion and allowing for a more regular viewing experience.
• Continuous Zoom: The microscope offers a continuous zoom range of 6.5X to 52X, allowing for pinpoint magnification and flexibility during observation.
• Touch Type Fixed Gear Variable Magnification: The microscope features a touch type fixed gear variable magnification design, providing a silky touch and easy magnification switching.
• Trinocular Function: The microscope can be easily switched to trinocular function, allowing for real-time transmission and sharing of images.
• High-Quality Optical Components: The microscope features high-quality optical components, including a CCD 0.45X CTV adapter, providing a clearer and more detailed image.
• Dust-Proof Design: The microscope head features an advanced dust-proof design, effectively isolating the intrusion of external dust and oil smoke.
• Unique Inward-Angled V-Shaped Optical Design: The microscope features a unique inward-angled V-shaped optical design, allowing for more efficient light travel and focus.
• Ultra-High Zoom Ratio: The microscope offers an ultra-high zoom ratio design, allowing for free adjustment of magnification in the 1:8 range.
• Comfortable Working Distance: The microscope maintains a comfortable working distance of 115mm, reducing fatigue and improving observation stability and accuracy.
• IML Process Manufacturing: The microscope is manufactured using the new IML process, providing a unique appearance charm and qualitative leap in performance.

Specifications:

• Adjustable eyepieces: PL 10X/26MM
• Zoom ratio: 1:8
• Objective Working distance: 115mm(Default)
• Objective Magnification: 0.65X/5.2X(Default)
• Objective Visual field: 36.61mm/4.6mm(Default)
• Observation head: 45 tilt, 360 rotation, pupil distance 54~76mm, bilateral visibility adjustment ±5 diopter
• Adjustable eyepieces: Standard configuration: PL10X26, flat-angle field eyepiece for the convenience of observers wearing glasses
• Working distance: 115mm
• Magnification: 6.5X~52X, standard eyepiece, continuous variable magnification
• Focus bracket: The inner diameter is 76mm, and the column bore diameter is 32mm
• Objective: 0.65X~5.2X continuous variable magnification, objective magnification ratio 1:8, to ensure the image plane parfocal
• Work platform size: 320*260mm
• Base: B11 Column type large flat base, can be equipped with other bases
• Dimensions: 424*328*250mm

Package Includes:

• 1 x Microscope Head
• 1 x Microscope Frame
• 2 x PL10X26 Eyepiece
• 2 x Eye Mask
• 1 x CTV 0.45X Adapter
• 1 x Ring Light
• 1 x Column
• 1 x Limit Block
• 1 x B11 Base
