Mechanic TI-08 3D Infrared Thermal Imaging Analyzer - Motherboard PCB Fault Detection

Mechanic TI-08 3D Infrared Thermal Imaging Analyzer for Motherboard PCB Fault Detection

Features:

• **Professional Motherboard Testing Equipment**: 3D Infrared Thermal Imaging Analyzer for faster and more accurate maintenance.
• One-click fault quick check, quickly locate mainboard faults and support one-click leakage detection
• **3D Thermal Field Release Analysis**: Visual display of temperature changes.
• Antistatic base high-temperature resistant silicone aluminum alloy base plate
• Military-grade high-resolution infrared lens, no visible light camera, can clearly show the outline minimalist design, high performance, mechanical appearance, and even more impeccable cost performance
• **High-Precision Temperature Measurement**: 52000-point effective temperature measurement (192x256) full-frame infrared detection
• PC software independently developed, compatible with more than 90% of the computer systems on the market
• A quick check of leakage current, quickly locate temperature anomalies based on the real-time temperature and fine-tune the temperature range to troubleshoot faults
• When the temperature exceeds the set temperature, the image flashes a red box and sounds an alarm, the function can be used to track the highest temperature point on the screen and mark the temperature
• **Special Mode Innovation**: For product evaluation and heat distribution analysis, 3D thermal field mode is more intuitive, and 2D thermal field area curve recording is more detailed
• According to different use scenarios switch different color swatches 5 different development color swatches
• For heat distribution design optimization, fault differentiation comparison verification region temperature curve comparison record, superposition comparison, and so on
• **360° Fine-Tuning**: Quickly adjust the lens direction/distance according to demand, a stable structure/fast/convenient
• Prevent the lens from striking the motherboard under test when quickly adjusting the position, and limit the minimum focal length range
• **High Temperature Resistance**: Up to 500℃, prevents the maintenance of heat insulation pad carbonization, anti-static

Specification:

• Product model: Mechanic 3D Infrared Thermal Imaging Analyzer
• Product model: TI-08
• Product size: 285*220*172mm
• Packing size: 270*205*95mm
• Net weight: 1.3KG
• Gross weight: 1.75Kg
• Resolving power: 256 x192 pixels
• Temperature measurement distance: 30mm-150mm
• Device interface: USB Type-C
• Lens field of view angle: 56x42
• Image storage format: JPG
• Video storage format: MP4

Package includes:

• 1 x Infrared Thermal Imaging Analyzer
