Mega-Idea Super IR Cam 2S Pro: 3D Infrared Thermal Imaging Camera for PCB Short Circuit Diagnosis

Mega-Idea Super IR Cam 2S Pro 3D Infrared Thermal Imaging Analyzing Camera for PCB Short Circuit Diagnosis

Features:

• **Heat Distribution Analysis**: Available for evaluators, the 3D effect mode can better display the heat distribution.
• **Multi-Area Curve Analysis**: Available for R&D personnel, the rectangular area curve is divided into multiple areas to view the display of different heat bands.
• Professional motherboard testing device, to help improve work efficiency.
• Say goodbye to out of dated and complicated motherboard testing methods.
• **Electricity Leakage Quick Check**: Location of Electricity Leakage Quick Check PCBA Electricity Leakage Defects.
• Electricity Leakage Quick Check is to quickly locate the abnormal temperature according to the real-time temperature, by adjusting the temperature range to troubleshoot the defect in detail.
• When the high-temperature alarm switch is turned on and the temperature threshold number is set, so when the temperature at any point in the home screen exceeds the threshold, the alarm will sound and the home screen will flash with a red frame.
• **Product Evaluation and Heat Distribution Analysis**: The professional model focuses on product evaluation and heat distribution analysis, such as the rationality analysis of the thermal structure design of the circuit board, the design of the heat dissipation efficiency of the product, etc.
• When there is a very small current leakage or a large interference source is nearby, the "Electricity Leakage Quick Check" cannot easily locate the leakage component.
• Adjust the temperature range to change the image contrast to locate the leakage component.
• Adjust the height of the camera quickly according to requirements Stable structure, quick and convenient.

Comparison of Mega-ldea iR 2s and iR 2s Pro:

• Upgraded focusing distance, control image clearance.
• Upgraded vertical adjusting column, widened the focusing range.

Package includes:

• 1 x Infrared Thermal Imaging Analyzing Camera
