Miniware TS101 USB Portable Adjustable Temperature Electric Soldering Iron

Miniware TS101 USB Portable Adjustable Temperature Electric Soldering Iron

Upgraded Performance and Functions
The TS101 is an upgraded version of the TS100, optimized for improved user experience with enhanced performance and functions.

Features:

• **Improved User Experience**: Based on TS100, TS101 is upgraded and optimized in performance and functions to improve user experience
• **Enhanced Display**: Larger 128 * 32 pixels OLED screen displays more heat data
• **Classic Operation**: The classic A-B key operation continues the TS100 operation habit and reduces the user learning cost
• **Easy Soldering Iron Head Replacement**: The insert end of the soldering iron head of the controller is fixed with a ball screw, no need to loosen the hexagonal screw before inserting and removing the soldering iron head
• **Practical Accessory**: A new handy and practical accessory, a cat-like non-slip cap that not only acts as a simple stand to support the iron and prevent it from rolling but also can be used for finger non-slip and removing the soldering tip
• **Dual Power Input**: TS101 soldering iron adopts DC and PD dual power input. The power range of the popular DC5525 interface has been extended to DC 9-24V (up to 65W)
• **Faster Firmware Upgrades**: The USB-C interface replaces the original Micro USB interface for firmware upgrades and is used as a standard PD power input up to 45W
• **Optimized Temperature Range**: The temperature adjustment range is also optimized to 50-400℃ to adapt to more application scenarios
• **Intelligent Operation**: TS101 menu Settings are more detailed, and the newly added "Boost" heating function can heat up quickly in a short time to meet the welding requirements of special scenarios
• **Compatibility**: TS101 and TS100 use the same soldering tip, so your existing TS100 tip can continue to be used for this upgraded version of the soldering iron

Summary:**
**Improved performance and functions, enhanced display, easy soldering iron head replacement, practical accessory, dual power input, faster firmware upgrades, optimized temperature range, intelligent operation, and compatibility with TS100 tips.**

Specification:

• Shell color: Dark Gray/Blue
• USB Interface: USB-C (Power supply and connection to computer)
• Working Voltage: DC 9-24V 9-65W(Max)
• Power: PD 9~28V 9~90W(Max)
• Power Input: DC 5525 Wide Voltage, PD3.1
• Temperature Range: 50-400℃
• Temperature Stability: ±2%
• Tip Resistance: <2Ω
• Ground Controller Size: L98mm, φ16.5mm
• Tip Size: L105mm, φ15.5mm (Different models of tips will be slightly different.)
• Weight: 33g (Controller+Tip)

Package includes:

• 1 x TS101 Controller
• 1 x Soldering Tip (TS-BC2)
• 1 x Anti-slip Cap
• 1 x USB-C Silicone Cable
