V12.25 XGECU T48 TL866II Plus High-speed Flash EPROM Universal Programmer with Adapters

Newest V12.25 XGECU T48 TL866II Plus High-speed Flash EPROM Universal Programmer with Adapters

Wide Range of Support:

• EMMC
• PARALLEL NAND
• SPINAND
• GAL/PAL
• MCU(51/AVR/PIC)
• EPROM 27/28/29/39/49/50
• SERIALS: 24/25/26/35/45/93/95
• 74 LOGIC IC VISUAL TEST
• SRAM TEST

EMMC Function Introduction:

**Summary: Supports Read and Write speeds up to 17M Bytes/s, Max capacity: 256GB, ISP in-circuit programming, and more**

• Read and write speeds up to 17M Bytes /s, Max capacity: 256GB
• Support ISP in-circuit programming
• 1b MODE speed: 4.7MB/s 4b Mode 17MB/s
• Analysis EMMC function
• show EMMC manufacturing and device lifetime information
• show memory usage of 8 partitions
• Each partition shows whether it is write-protected
• Shows whether the entire chip is temporarily or permanently write protected
• Show whether the chip is password-protected
• Show whether the EMMC uses a 32-bit security authentication code to write to the RPMB.
• Show other important parameters of ECSD/CSD/CID
• Read/write functions (all functions can be completed with one key)
• Read CID CSD ECSD.
• Clear full-chip temporary write protection before programming
• Clear temporary write protection groups before programming
• Erase chip before programming
• Blank check the chip before programming
• Programming 32-bit authentication key password verification
• Partition Config
• Read and Programming to BOOT1
• Read and Programming to BOOT2
• Read and Programming to RPMB
• Read and Programming to GPP1/GPP2/GPP3/GPP4
• Read and Programming user data(User Area)
• Setting temporary write protection groups
• Setting permanent write protection groups
• Setting password(or reset password)
• Programming ECSD
• Programming CSD
• Automatically verify all the above operations after Programming

NAND Function Introduction:

**Summary: Supports speeds up to 3.2M Bytes/s of S_NAND, 6MB/s of P_NAND, MAX capacity:256G, and more**

• Speeds up to 3.2M Bytes /s of S_NAND
• 6MB/s of P_NAND,MAX capacity:256G
• Support ISP in-circuit programming
• for SPI NAND

Function:

• Support OTP programming
• Support internal ECC on/off function
• Support UID(unique signature)reading
• Support multiple partitions and multiple file operations
• Support NAND parameter custom function (new chips can be added by custom parameters)
• The programming clock speed and VCC/VIO voltage are adjustable.
• Support 1.8V and 16-bit device
• Support ISP programming of SPI NAND (MAX 3.2MB/s)
• Package type: DIP8/SOIC8/SOIC16/WSON8/BGA24/BGA63/TSOP48

Specification:

• 32-bit MCU120 MHZ USB2.0 HS480MHZ transmission
• 40+16=56 I0 output pins, extremely high reliability
• Stable and reliable 1SP interface, line length of 25CM or more, reliable communication at 30MHZ.
• Maximum clock frequency up to 30MHZ-40MHZ for 25 series/EMMC online programming.
• VCC voltage 1.8-6.5V64 level adjustable; VPP voltage 9.0-25V64 level adjustable.
• I0 communication signal voltage 1.8V-3.6V adjustable
• VCC120MA-320MA overcurrent protection continuously adjustable; VPP120MA overcurrent protection
• Power consumption: 5V<500MA static power consumption: 80MA all chips without external power supply
• Internal multi-protection: overvoltage protection / reverse connection protection / three-level overcurrent protection voltage is too low to mention the deficit
• Open self-test function, self-test each way VPP/VCC/GND/IO

Package Includes:

• 1 x Host
• 10 x Adapters
