Qianli UVC17 7" Integrated UV Curing Lamp with Timing Function

Qianli UVC17 7-inch Integrated UV Curing Lamp with Timing Function

Features:

• UVC17 integrated UV curing lamp frees your hands, fast curing, dual wavelengths of UV LED chips, curved surfaces wrinkle-free, powerful heat dissipation, large power, small body, big curing area (Summary: Fast and efficient curing)
• Free your hands, fast curing, small size, lightweight, large curing area (Summary: Convenient and portable)
• Large digital display + Shortcut button, adjustable control panel display, intuitive and accurate (Summary: Easy to use)
• 180*95mm curing area, applicable to almost all mobile phone sizes on the market (Summary: Wide compatibility)
• Dual wavelengths of UV LED chips are mixed arrangement, 365/395 UV LED chips are mixed arrangement to help the curved screen cure faster and more thoroughly (Summary: Advanced UV LED technology)
• 22 imported 365/395 dual wavelength UV LED chips can cure UV adhesive, OCA, solder mask, etc (Summary: Versatile curing capabilities)
• Large cooling fan, suitable for curved/flat screen/OCA screen glass laminating, wrinkle-free, LCD curing, etc (Summary: Effective cooling system)

Steps:

• Apply UV curing glue to the screen to be repaired
• Then attach the mobile phone screen glass to the screen
• Different screens require different UV exposure times for repair
• The screen can be taken out once the curing is complete

Specification:

• Brand: QianLi
• Product Name: UVC17 Integrated UV Curing Lamp
• Quantity of UV LED chips: 22
• Power Consumption: 60W
• Dual wavelengths of UV LED chips: 365/395
• Main Applications: Mainly used for LCD screen repair, curing UV adhesive, optically clear adhesive, printing ink, resin adhesive, RMB inspection, fluorescent agent detection, etc.
• Net Weight: 823g
• Product Size: 98*180*70mm
• Package Size: 253*172*133mm

Package includes:

• 1 x UV Lamp
• 1 x Power Cable
