RF4 RF6565TVD2 6.5-65X Synchronous Zoom Trinocular Stereo Microscope, Aluminum Alloy Base

RF4 RF6565TVD2 6.5-65X Synchronous Zoom Trinocular Stereo Microscope with Aluminum Alloy Base

Product Overview

This RF4 RF6565TVD2 trinocular stereo microscope is designed for industrial inspection, research, and education. It features a 45-degree inclined 360-degree swiveling trinocular head, continuous zoom magnification from 6.5X to 65X, and a WF10X/22MM eyepiece. The microscope comes with an aluminum alloy base, 144 adjustable LED lights, and a dustproof lens.

Key Features

• Magnification:** Continuous zoom 6.5X to 65X
• **Head:** 45-degree inclined 360-degree swiveling trinocular
• **Eyepiece:** WF10X/22MM
• **Objective:** 0.65-6.5X
• **Camera connector:** 0.5X
• **Monitor and eyepiece:** Synchronous zoom
• **Stand:** 410*300mm
• **Accessories:** 144 adjustable led lights & dust proof Lens

Support Parameters

• **Column aperture:** Φ32mm
• **Lens aperture:** Φ76mm
• **Center distance:** 155mm
• **Lifting range:** 50mm

Base Parameters

• **Base size:** 410*300mm
• **Pillar:** 240mm φ32mm
• **Silicone pad size:** 330*198mm

Wide-angle Eyepieces 10X/22

• **Magnification:** 10X
• **Wide field of view:** 22mm
• **Matching size:** 30mm
• **Applicable models:** Stereoscopic, fixed, and continuous magnification microscopes

0.5X CTV Len

• **Material:** All metal, aluminum alloy, and copper chrome-plated bayonet
• **Adapter ring:** Manual focus, can use LCD to focus
• **Transparent mirror:** Helps achieve synchronous zooming

144 LED Ring Light

• **Input:** AC 100~240V 50/60Hz
• **Output:** DC 12V, Max 700mA
• **Light color:** White
• **Number of lights:** 144 LEDs
• **Inside diameter:** 60mm

What's in the Box

• **1 x Microscope**
• **1 x Aluminum Alloy Plate**
• **1 x 144 LED Light**
• **1 x Dustproof Len**
• **1 x 0.5X CTV Lens**
• **1 x Silicone Pad**
