RF4 RF7050TVD2-YS010W 7-50X Trinocular Microscope with 10" 1080P HD Monitor & Synchronous Zoom

RF4 RF7050TVD2-YS010W 7-50X Synchronous Zoom Trinocular Microscope with 10-inch 1080P HD Monitor

Overview

This trinocular microscope offers continuous zoom magnification from 7.0X to 50X and comes with a 10-inch 1080P HD monitor, making it ideal for a variety of applications including inspection, dissection, and observation.

Features:

• **Summary:** 7.0X-50X trinocular microscope with 10-inch 1080P HD monitor and multifunctional aluminum alloy repair base.
• Magnification: Big continuous zoom 7.0X to 50X
• Head: 45-degree inclined 360-degree swiveling trinocular
• Eyepiece: WF10X/22MM Adjust the focal
• Barlow Lens: 0.5X & 0.7&2.0X(Optional)
• Objective: 0.70~5.0X
• Camera connector: 1/2CTV
• Monitor and eyepiece. Synchronous zoom
• Camera: Different models optional
• Boom Stand: 250mm φ32mm pillar, 410*300mm Plate
• Accessories: 144 adjustable LED light & dustproof Lens

Base Parameters:

• Base size: 410*300mm
• Pillar: 240mm φ32mm
• Silicone pad size: 330*198mm

Monitor:

• Model Number: YS101W
• Resolution:1080P
• Monitor size: 10-inch
• Aspect ratio: 16:10
• IPS display resolution: 1280*800
• Output port: HDMI
• Panel brightness: 400cd/m²
• Contrast: 1300:1 (Min.)(transmission)
• Viewing angle: IPS full view
• Display area: 215*121mm
• WIFI distance: Ten meters
• Display mode: IPS, always black display, transmissive

Wide-angle Eyepieces 10X/22:

• Magnification: 10X
• Wide field of view 22mm
• Matching size: 30mm
• Applicable models: Stereoscopic, fixed, and continuous magnification microscopes

0.5X CTV Len:

• The material is all metal, the black part is aluminum alloy, and the silver part is a copper chrome-plated bayonet
• The adapter ring can use LCD to focus, this kind of focus method is manual focus
• The adapter has a transparent mirror inside, which can help the microscope display and the other display achieve synchronous zooming

144 LED Ring Light:

• Input: AC 100~240V 50/60Hz
• Output: DC 12V, Max 700mA
• Light color: White
• Number of lights: 144 LEDs
• Inside diameter: 60mm

Package includes:

• 1 x Microscope
• 1 x Aluminum alloy plate
• 1 x Silicone pad
• 1 x HD Monitor
• 1 x 144 LED light
• 1 x Dustproof len
• 1 x 0.5X CTV lens
