RT809F ISP LCD USD Programmer Repair Tools for 24-25-93 Series IC with Universal Adapters

RT809F ISP LCD USD Programmer Repair Tools 24-25-93 Series IC with Full Universal Adapters

Features:

• Read and write various memory chips, including 8-pin and 16-pin chips commonly used on computer motherboards, laptops, LCDs, routers, and home appliances.
• Read and write memory SPD DDR1/DDR2/DDR3 Free demolition chip, especially support 34C02 and other special part numbers
  (Summary: Support various memory chips)
• Support laptop 8 pins and 14 pin password chip and battery chip (especially 24RF08/6480AR/BR9080/9016 special part numbers
• Support all series of 24, IIC EEPROM Memory. Besides, it can automatically identify chip models from 24C01 to 24C16, Automatic identity of the write protection level of the 24 series' 7th pin
• Support all series of 25 and 26 SPI FLASH Memory, support identifying the chips part number automatically, the capacity is up to 256Mbit.
• Support all series 93 MircroWire Memory, including Japanese special chips
• It is the only programmer which has the function of supporting the RTD2120 chip’s double bank read and write online. Including the BANK0 which the firmware is in and the BANK1 area, which the menu is in. It can read double BANK in only 6 seconds. Support RTD2122 ‘s three BANK read and write online
• Support reading and writing DDC-EDID data of LCD and LCD TV online. Very easy to solve EDID data problems
• Support reading and writing laptop screen EDID data online, very easy to solve the problem of the laptop’s chosen screen. Our store have screen wires sale
• Support for Triumph, Leroy, Ding Branch, Rainbow Star, Kang Yue, and Wang Jie general driver board. Write the driver board MCU by VGA port without taking the components out of the board. The programmer software has a new additional function, it can restore the chips. If the board has been damaged when programming, it can work normally with this function. Reduce many matters
• Support to read and write the firmware of LCD and TV motherboard online and out of the line. chipset solution, you can use the official ISP software or third-party software, take into account the functions’ integrity and the user's ease of use
• Support P Philips, AOC, BENQ, and NESO use NT68F63/NT68F632/NT68F633 series MofCU and WT61P4 models. Can read and write programmer free disassemble. The LCD has a common problem of missing programmers, you can solve this problem free disassemble it. It has a special function of reading MCU original programmers online. It can read and save original programmers from the good MCU. Besides, it supports the latest SE1059 series’ reading and writing. Easy to solve black screen problems.
• Support WINBOND series MCU’s programming online, such as W78E65P-40, it can replace the MCU of M6759, SM5964, SM89516, P89C51RD, and TP2804 which are very easy be damaged
• Support MTK series LCD and DVD program online. Such as MT2389, MT1379, MT8223 and 8226, etc
• Support SURPLUS series DVD program online. Such as 8202D 8202S, 8202L, 8281 and 8200 etc
• Online support in nine series satellite receiver upgrade crack and the brick machine repair; including of Guoxin, Haier, China and Asia, movement program online to read and write and demolition chip reader upgrade feature
• USB-powered, communication automatically detects the programmer's self-test mode, the original ISP online programming mode pin disconnection detection, target board power detection function, offline reading and writing pin-contact detection, and other special features during the burning of various types of failures can be identified, and prompt, effective solution to read and write errors
• Programming the internal high-speed MCU control to upgrade PC client software to complete the programmer's feature upgrades, more compatible models; using USB interface, power supply, and control, eliminating the need for the bulky power adapter, easier to use; locking seat of the programming interface, there are anti-static and port the IO protection measures to ensure the reliability of the programmer
• Recordable models constantly add, if there are special needs, you can contact the company, and part of the chip models can remotely add. 24,25,26,93 series chip and official ISP software, users can also customize the video tutorial to add, convenient to use. Gift 8G procedures and information, and provide long-term technical support, to welcome major brand service station orders, such as over one hundred customizable software LOGO and special features

Package includes:

• 1 x RT809F Programmer
• 1 x SOP8 IC test Clip with a base adapter
• 1 x SOP8 to DIP8 150mil Adapter (Gold Plating)
• 1 x SOP8 to DIP8 200-208mil Adapter (Gold Plating)
• 1 x SOP16 to DIP16 150mil Adapter (Gold Plating)
• 1 x SOP16 to DIP8 Adapter 300mil (Gold Plating)
• 1 x SOP8/SOP16/ MSOP8/sop8 to DIP16 simple adapter
• 1 x 1.8V Adapter
• 1 x TSSOP8/SSOP8 Adapter
• 1 x ICSP Board with 6P Wire
• 1 x KB9012 Board
• 1 x RT-SOP8-A simple Adapter
• 1 x USB Cable
• 1 x VGA Cable
