TBK-502 7" COF Constant Temperature Press Machine, Green Row Special

TBK-502 7-inch COF Green Row Special Constant Temperature Press Machine

Features:

• COF green row special constant temperature press, suitable for various industries' wire harness repair, Green row, Black row, Yellow row, Display cable, Touch cable, Backlight screen, Curved screen, etc
• **Summary:** Equipped with 4 high-definition CCD cameras and a 17-inch wide high-definition display for clear wiring line visibility.
• Platform multiple azimuth adjustments, and a micrometer for precise alignment.
• Place the product that needs to be repaired on the work platform adjust it in the multiple directions section and observe whether the display screen alignment is correct before starting.
• A variety of platforms/cutter heads are available, adapt platforms/cutter heads for different products.
• Can repair a variety of malfunctions, screen: no display, no touch, touch failure, black screen, blurry screen, abnormal display, cable breakage, screen cable out (cable problem), etc.
• Various industries/cable repair, products cover a wide range of industries, including medical equipment, energy vehicles, and communication modules waiting for industry ACF, COF, and other processes.
• HD footage, upper and lower HD alignment lens 2 million pixels CCD, super clear alignment.
• Flexible micrometer alignment LCD and cable arrangement, you can adjust the LCD and cables up, down, left, and right, it can be vacuum adsorbed in any position.
• PLC intelligent touch screen can control pressure and discharge, time, temperature, and tape transport. etc.Simple and precise settings.
• Teflon belt automatically rotates to free your hands Lead oxide material is durable and protects the blade with burn-proof cable.
• Most accessories are imported configurations, simple operation buttons are clear at a glance, more convenient to operate.

Specification:

• Model: 502
• Device power supply: AC 220V
• Equipment power: 800W
• Processing efficiency: 10-15S/Pcs
• Suitable for products: 2.4-7.0 inch
• LCD platform: 182*180mm
• Hot pressing accuracy: ±5um
• Working air source: 0.2-0.6Mpa
• Product name: COF constant temperature press
• Device functions: LCD screen cable binding and repair
• Suitable for products: Mobile phone screen, tablet projector, etc.
• Blade size: 54*1.5mm/64*0.6mm.
• Dimensions: 650*500*820mm
• Package Size: 750*600*950mm
• Product Weight: 73kg
• Repair brands: Huawei, Apple, Xiaomi, Samsung, OPPO, etc.

Package includes:

• 1 x Machine
• 1 x Power Cable
