TBK-958ZE 5W Purple Laser Screen Disassembling & Marking Machine

TBK-958ZE 5W Purple Laser Screen Disassembling and Marking Machine

Features:

• **Autofocus and High-Speed Precision**: High-speed automatic precision focus
• Activated carbon filtration exhaust: Multi-layer filtration, effectively adsorbing harmful gases
• High power cold light source: Strong material adaptability, all materials can be marked
• **All-Round Disassembly**: One machine for multiple uses, all-round disassembly, one machine for multiple uses
• Remove the phone screen, safe, quick-release cover
• Remove the back cover of the phone, remove the back cover glue to make disassembly easier
• Dismantle the phone stand, safe and quick removal of the bracket for re-use
• Rich drawing library for more accurate maintenance, covering the mainstream mobile phone models on the market, one-click call, and precise positioning make maintenance work more handy.
• Built-in activated carbon smoke exhaust, harmless and pollution-free, avoids the impact of smoke and dust generated during laser processing on operators and improves the comfort and safety of the working environment
• Smaller and lighter products, the product is small in size and light in weight, net weight: 25.6KG
• **Wide Application**: Unlimited possibilities, strong material adaptability, whether it is metal, plastic, glass, or other special materials, it can easily cope with it

Specification:

• Brand: TBK
• Model: TBK-958ZE
• Operating voltage: 110~220V
• Laser power: 5W
• Screen size: 20*15cm
• Laser wavelength: 355nm
• Repeatability: 0.001mm
• Marking speed: <10000mm/s
• Marking depth: 0.015~0.5mm
• Marking area: 170*170mm
• Marking line width: 0.05~0.01mm
• Marking accuracy: 0.001mm
• Net weight: 25.6kg
• Product size: 400*240*500mm

Package includes:

• 1 x Laser Machine
• 1 x Power Cable
• 1 x Hexagon Wrench Set
