Thermalright PA120 Mini: 6 Heat Pipe Twin Towers Air-Cooled Radiator for LGA1700 & AMD AM5

Thermalright PA120 Mini 6 Heat Pipe Twin Towers Air-cooled Radiator Support Inter LGA1700 AMD AM5

Product Overview

The Thermalright PA120 Mini is a high-performance air-cooled radiator designed for optimal heat dissipation and silent operation. With its unique reverse gravity heat pipe technology and 6mm heat pipe specification, this radiator is capable of handling high temperatures with ease.

Key Features:

• Reverse Gravity Heat Pipe Technology: 4th generation, 6*6mm heat pipe specification, 12cm twin tower AGHP Gen 4 for efficient heat dissipation.
• Dual Platform Optimization: Optimized for both Intel and AMD platforms, ensuring excellent heat dissipation performance.
• Lightning Speed Heat Dissipation: Solves the impact of reverse gravity in two installation directions: vertical/lying.
• High-Quality Materials: 0.4mm all-aluminum FIN fin with Phantom whitening antioxidant coating and Symmetrical mecha-type fin appearance.
• Fearless ITX Motherboard Compatibility: Classic and reliable compatibility with ITX motherboards.
• Excellent Tower Structure: Provides strength output for excellent tower structure and user experience.
• Easy Installation and Maintenance: SS2 buckle body with metal buckles, adaptable to various specifications, compatible with various CPU models, and easy to install and remove.

Specifications:

• Standard Sizes: 125*135*135mm
• Product Weight: 700g
• Number of Heat Pipes: 6mm heatpipe * 6
• Material: Pure copper heat pipe aluminum fins
• Close Fit Craft: Fins go through fin reflow soldering the copper bottom
• Support Platform: Intel: LGA:1700/115X/1200/2011/2066; AMD: AM5 AM4

Fan Specifications (TL-D12W):

• Fan size: 12*120*25mm
• Speed of the fan: 1500RPM+10% Max
• Rated voltage: DC 12V
• Rated current: 0.20A
• Fan pressure: 1.53MM H20(Max)
• Fan air volume: 66.87 CFM(Max)
• Operating noise: <25.6DB(A)
• Fan interface: 4Pin PWM
• Fan bearing: S-FDB Bearing

Package Includes:

• 1 x Radiator
