Thermalright TL-B8 / TL-B8W 80mm High Air Volume 4-Pin Silent Case Fan

Thermalright TL-B8/TL-B8W 80mm 4-Pin High Air Volume Small Silent Case Fan

Features:

• Adopt 9 fan blades golden tangent theory, and strive to achieve accurate performance output
• S-FDBV2.0 magnetic fluid dynamic bearing to solve the problem of fan blade jitter and vibration in lifting mode
• Micro-level fine-tuning of fan blades under the acoustic sampling system, emphasizing the balance of acoustic sensation and performance
• Double-sided silicone feet give better shock absorption protection
• Shaped line guard frame to strengthen the fan frame support strength
• Summary:** High-performance fan with advanced features for reduced noise and vibration

Specification:

TL-B8:

• Dimension: 80*80*25mm
• Weight: 90g
• Rated Speed: 2200 RPM±10% (Max)
• Noise Level: 24 dBA (Max)
• Air Flow: 34 CFM (Max)
• Air Pressure: 2.7 mm/H₂O (Max)
• Ampere: 0.1A
• Connector: 4 Pin PWM
• Bearing Type: S-FDB V2 Bearing

TL-B8W:

• Dimension: 80*80*25mm
• Weight: 90g
• Rated Speed: 2200 RPM±10% (Max)
• Noise Level: 24 dBA (Max)
• Air Flow: 34 CFM (Max)
• Air Pressure: 2.7 mm/H₂O (Max)
• Ampere: 0.05A
• Connector: 4 Pin PWM
• Bearing Type: S-FDB V2 Bearing

Package includes:

• 1 x Fan

Notes:** Thermalright fans use high-precision S-FDB bearings for sealed structure, with long durability, maintenance-free, and no need to add lubricant maintenance, please do not disassemble
