Tooltup ET120M Digital Oscilloscope: 120MHz Bandwidth, 500MSa / s Sampling Rate, Backlight HD Screen

Tooltop ET120M 500MSa/s Sampling Rate 120MHz Bandwidth Digital Oscilloscope with Backlight HD Screen

Features:

• With a 320*240 LCD screen, you can see the data more clearly
• With 120MHz analog bandwidth and 500MS/s sampling rate
• With the function of 4 speeds of square wave signal output: 1kHz,10KHz,100KHz,1MHz.
• 12 kinds of parameter measurement: Vpp, Vrms, Vavg, Vp, Vmax, Vmin, F, T, T+, T-, Du+, Du-
• Functions: one key oscilloscope, three scan modes: auto, normal, and single, 12 kinds of test data, can store 2500 waveforms, support thumbnail browsing
• Waveform parameters such as time base, amplitude, and trigger slope can be set by themselves
• Silicone protective cover on both sides of the fuselage, anti-slip, anti-fall, and shockproof, comfortable to feel
• Small size and light, so you can take it anywhere you want to use it
• **Summary:** High-performance digital oscilloscope with advanced features and compact design

Specifications:

• Display: 320*240 LCD Screen
• Low power: Yes
• Display area: 50*40mm
• Save: 2500 DSO waveforms
• Backlight: White, 8 levels of brightness
• Impedance: 1X-1MQ/10X-10MQ
• Size: 124*80*35mm
• Weight: About 180g
• Battery: Lithium battery
• Use conditions: 0℃~+40℃,<75%RH
• Auto shutdown: No operation for 15 mins
• Save conditions: -10℃~+60℃; <90%RH
• Waveform bandwidth: 120MHz
• Channel quantity: Single
• Max test voltage: 1X :80 Vpp 10X: 800 Vpp
• Coupling method: DC/AC
• Signal outputs: 1KHz,10KHz,100KHz,1MHz
• Screen resolution: 320×240
• Voltage accuracy: 10%
• Frequency accuracy: 1%
• Storage Depth: 12.8div
• Input impedance: 1MΩ
• Vertical Sensitivity: 50mV≈100V
• Time base range: 6nS~50S
• Trigger mode: Auto/Normal/Single
• Trigger slope: Rising Falling
• Rising time: <3nS
• Charging: DC 5V 1A/2A

Package includes:

• 1 x Oscilloscope
• 1 x Probe
• 1 x Charging Cable
