UT-CS09D 3000A AC Current Flexible Clamp Multimeter by UNI-T for UT206B / UT208B

UNI-T UT-CS09D 3000A AC Current Flexible Clamp Multimeter Applicable to UT206B/UT208B

Overview

This flexible clamp multimeter is designed to measure AC current up to 3000A and is compatible with UT206B/UT208B multimeters.

Features:

• Flex clamp can measure from 1.5A to 3000A current (Highly Accurate Measurements)
• 1m drop proof (Durable and Rugged Design)
• Robust terminal connection (Reliable and Secure Connection)
• Directly displays current when connected to UT206B/208B (Easy to Use)

Specification:

• Certifications: CE, RoHS, cETLus
• Safety rating: CAT IV 600V
• AC current (A): 30A/300A/3000A
• Frequency response: 45Hz~500Hz
• Flex clamp size: 45.7cm (18 inches)
• Operating temperature: 0℃~50℃
• Storage temperature: -20°C~60°C
• Storage humidity: ≤80%RH
• Low battery indication: About 3.3V
• Category Rating: CAT IV 600V
• Power: 1.5V battery (R03) x 3 (Not included)
• Product net weight: 260g
• Product size: 267*119.4*34mm
• Standard accessories: BNC adapter

Package includes:

• 1 x Flexible Clamp Multimeter (No battery included)
• 1 x BNC adapter
