UT373 UNI-T Singal Trigger Laser High Precision Digital Non-contact Tachometer

UNI-T UT373 Singal Trigger Laser High Precision Digital Non-contact Tachometer

Overview: This digital non-contact tachometer is designed for high precision RPM measurement and revolution counting. It features a single trigger laser and is ideal for measuring rotating speed and counting revolutions.

Features:

• Auto range
• Up to 99999 display; overload display "OL"
• RPM measurement and revolution count
• Max/Min data hold
• Singal trigger/laser-on indication
• Low battery/auto power-off indication
• LCD backlight
• Summary:** High precision, non-contact, single trigger laser tachometer with auto range and max/min data hold.

Specifications:

• RPM measurement: 10.0~99999RPM
• Counting measurement: 0~99999 counts
• Auto range: Yes
• Auto power off: Yes
• Low battery indication: Yes
• Laser-on indication: Yes
• Data hold: Yes
• MAX/MIN: Yes
• Rotating speed/count function switching: Yes
• Overload indication: Yes
• LCD backlight: Yes
• Refresh rate: 1s to 7s (>120rpm for 1s)
• Sensor type: Photodiode and laser tube
• Target distance: 50mm~200mm
• Measuring angle: ±30° from perpendicular
• Drop test: 1m
• Power: 1.5V battery (R03) x 3(not included)
• Display: 5-digit segment code; 99999 max display
• Product color: Red and grey
• Product net weight: 100g (excluding battery)
• Product size: 183.8*56*34mm

Package Includes:

• 1 x Mini tachometer (not includes battery)
• 6 x Reflective tape
