UNI-T UTi256M Type-C Thermal Imager for Mobile Phones - Thermographic PCB Circuit Failure Test

UNI-T UTi256M Type-C PCB Circuit Failure Test Thermographic Thermal Imager for Mobile Phones

Features:

• Frame rate 25Hz, support for hot plug links, fast image response, improved work efficiency
• UTi256M supports integration and picture-in-picture mode with a mobile phone visible light lens
• Photography and video recording function, users can take photos, record videos, and store images
• Analysis objects can be added, point, line and rectangle analysis objects can be added, and more temperature information can be learned through analysis
• Manual isothermal function, a variety of manual isothermal setting modes can be set, so that users can focus on viewing the temperature position
• High and low-temperature alarms, The user can define high/low-temperature threshold
• 360 automatic rotation of the image
• Product application, it can be used for power distribution cabinet detection, electronic circuit board detection, HVAC detection, etc
• Summary:** This thermal imager offers advanced features for efficient and accurate thermal imaging and analysis.

Specification:

• Measurement of temperature: -20℃~200°C(-4℉~392F) ±2°C/±2% Take the maximum
• Sensor: Uncooled vanadium oxide
• Rate of emissivity: 0.95 (Default) 0.01-1.00
• Thermal image pixel: 256×192(49152)
• Thermal imaging pixel size: 12μm
• Infrared spectral bandwidth: 8-14μm
• Swatches: Iron red, rainbow, black hot, white hot, red hot, lava, high contrast rainbow
• The angle of view: 56.0°(H)X42.2°0
• IFOV: 3.8mrad
• Focal length of lens: 3.2mm
• Focus mode: Fixed focus
• Sensitivity of sensitivity: <50mK@25C
• Frequency of frames: 25Hz
• Analysis of temperature: Point, line, rectangle, circle (add up to 3 for each type)
• Temperature measuring display: Center point temperature, high and low-temperature tracking
• Temperature measuring unit: Celsius, Fahrenheit
• High and low-temperature alarm: Yes
• Image mode: Thermal imaging, fusion, picture in picture
• Image capture mode: Take photos and videos
• Image saving format: JPG
• Image browsing: Rotation, graffiti marking, temperature analysis, deletion, retention
• Equipment communication: Type-C USB
• Language: Chinese/English
• Mobile phone APP: (Support Google Play)
• Mobile phone system: Android 6.0 up
• Operating power consumption: <350mW
• Certification: FCC CE UKCA ROHS
• Operating temperature: -10℃~50℃ (14°F~122°F)
• Storage temperature: -20°C~60℃ (-4℉~140℉)
• Storage humidity: 10%~95%Rh (Non-condensing)

Package includes:

• 1 x UTi256M
• 1 x Type-C Cable
