Wanptek NPS1203W 120V / 3A High Precision Dual Output DC Power Supply with 3-Digits LED Display

Wanptek NPS1203W 120V/3A 3-Digits LED Display High Precision Dual Output Adjustable DC Power Supply

Features:

• LED 3 digits display voltage, current, and power, high precision with single channel output
• Voltage stabilization, current limiting, and simple operation feature the DC power supply
• Over voltage protection(OVP), over current protection(OCP) with over temperature protection
• The continuously adjustable output of voltage and current with fine regulating and coarse regulating
• Automatic conversion of voltage stabilizing and current stabilizing, adopt current limiting protection mode, and any external service state will not be damaged
• With a replaceable fuse for safe use, convenient to change the fuse
• Applied in production line tests, electrical maintenance, aging products, battery charging, laboratories scientific research and teaching, and all other need DC regulated power supply
• Summary:** High precision dual output adjustable DC power supply with advanced protection features and wide application range

Specifications:

• Model: NPS1203W
• Color: Black/White
• Plug Type: AU / EU / US / UK (Optional)
• Output Voltage: 0～120V
• Output Current: 0～3A
• Output Power: 360W
• Input Voltage: AC 230V/115V ± 10%; 50Hz/60Hz
• Working Temperature: 0~40℃; Relative Humidity: <80%RH
• Storage Temperature: -10~70℃; Relative Humidity: <70%RH
• Three-window digital tube display: Voltage, Current, Power
• Display Accuracy: 0.5% ± digits
• Display Resolution: Voltage 0.1V; Current 0.01A; Power 0.1W/1W
• Item Size: Approx. 230 * 130 * 70mm
• Item Weight: 1372g
• Package Weight: 1550g
• Package Size: Approx. 29 * 18 * 10.5cm

CONSTANT VOLTAGE CV:

• Voltage Stability: 0.1% ± 3mV
• Load Stability: 0.2% ± 3mV
• Ripple Voltage: =0.5% Vp-p
• 0 to rated voltage continuously adjustable
• Summary:** High stability and precision voltage output with adjustable range

CONSTANT VOLTAGE CC:

• Current Stability: 0.1% ± 3mA
• Load Stability: 0.2% ± 3mA
• Ripple Current: =0.5% Vp-p
• Recovery Time: =500μS
• Temperature Coefficient: =100ppm/℃
• 0 to rated current continuously adjustable
• Summary:** High stability and precision current output with adjustable range

Package includes:

• 1 x DC Power Supply
• 1 x Power Cord
• 1 x Alligator Clip Line
