Overview

This mini development board features a dual-core Arm Cortex M0+ processor, 264KB of SRAM, and 4MB of onboard Flash memory, making it a powerful and flexible platform for your projects.

Features:

• Dual-core Performance: Dual-core Arm Cortex M0+ processor, flexible clock running up to 133 MHz
• Memory and Storage: 264KB of SRAM, and 4MB of onboard Flash memory
• Onboard Ethernet: Onboard CH9120 with integrated TCP/IP protocol stack
• GPIO and Compatibility: 14 × multi-function GPIO pins, compatible with some Pico HATs
• Castellated Module: Allows soldering directly to carrier boards
• Easy Programming: Drag-and-drop programming using mass storage over USB
• PIO State Machines: 8 × Programmable I/O (PIO) state machines for custom peripheral support
• Tiny and Integrated: Tiny Size And Easy Integration, Castellated Holes With Immersion Gold Design, Highly Integrated Packaging
• Multiple Application Support: Supports Multiple Ways To Be Embedded Into Various Product Applications
• Communication Modes: Supports Multiple Communication Modes, **Summary: TCP Server / TCP Client / UDP Server / UDP**
• Software Support: Supports C/C++, MicroPython, Arduino
• Comprehensive Resources: Comprehensive SDK, Dev Resources, Tutorials to Help You Easily Get Started
• Flexible Development: Configurable Pin Function (This product is without a pre-soldered header by default), Allows Flexible Development And Integration

What's in the Box:

• 1 x Development Board
