Z3X Easy Jtag Plus Box Full Version with EMMC and NAND Sockets

Z3x Easy Jtag Plus Box - Full Version With eMMC Socket

This upgraded PLUS version features ultra-fast data transfer, has the possibility of increasing functionality in the future: hardware of the new box is ready to support new protocols like UFS* and NAND*.

Box Features

• One click device repair
• Boot repair
• Data recovery
• eMMC firmware repair
• Partition management
• eMMC service operations
• SPI memory programming

**Summary: Fast and powerful device repair and data recovery solution with advanced features**

Socket Features

• Combining the top quality materials with best engineering and elegantly designed hardware for the powerful eMMC Socket.
• Made from the high quality materials
• Over 10K cycles of lifetime performance in your service center
• Wide range of eMMC IC supported by: BGA153/169, BGA162/186, BGA221, BGA529
• High-speed up to 30 MB per second over 8 bit bus.
• EMI resistant design, low noise components
• Integrated power logic. Additional power source is no more need
• Surge protection - smart fuse driven (0.5A threshold)

**Summary: High-quality eMMC socket with advanced features and long lifespan**

Software Features

• DUMP AND PINOUTS DATABASE

Free access to large dump and pinouts database and constantly updated software tools

• EASY JTAG TOOL

The main application allowing you to use most of the product features. It's the most powerful tool of all

• EASY JTAG PLUS TOOL

Lightweight software, made especially for mobile phones repair, eMMC memory chips replacement and user data recovery

• EASY JTAG SPI FLASHER

Identifying, reading, writing, verifying and erasing flash chips. It is designed to flash BIOS images on mainboards, routers, e.t.c.

• EASY JTAG SINGLE PACKAGE REPAIR

Create user customized repair packages. This is partition layout, pinout, eMMC preconfig and instructions

• EASY JTAG API

Access to most useful box functionality to create your own decisions

**Summary: Advanced software features for efficient device repair and data recovery**

Main benefits of new Z3x Easy Jtag Plus Box

• Updated CPU AT SAM3X8E vs LPC1768 in old box.
• Updated FPGA SPARTAN6 vs SPARTAN3 in old box
• Updated Power Logic – Full Digital PWM with ADC control.
• MicroUSB Connector if additional power required.
• VCC and VCCQ overload protection.
• Updated host interface: USB 2.0 Device/Mini Host: 480 Mbps
• Integrated ISP engine: Z3X High Power Pro Engine
• ISP Support 1 and 4 bit connection now **
• Added eMMC 8 bit high speed interface up to 48Mhz
• Integrated NAND engine: NFC with 4 Kbyte RAM buffer and ECC
• Integrated M-PHY interface.
• Integrated SPI/I2C engine: up to 65 MHz for HSMCI and SPI clock lines
• Integrated Self Test Core that exclude 90% faults in production.
• Integrated CCID Card Reader for Z3X Software Use

**Summary: Upgraded hardware with advanced features and improved performance**

What you get with new hardware :

• Box to Host PC speed increase up to 35MB/sec
• JTAG Interface speed increase 20%
• eMMC ISP Speed increase up to 4MB/sec
• eMMC 8 Bit Speed up to 26MB/sec
• Compatibility with 99.9 host PC systems and OSes
• Compatibility with old Easy JTAG G1 ISP adapters ( 1bit )
• Adapter-less ISP ( all stuff inside the box )
• Compatibility with all market popular eMMC sockets ( 8 bit )
• True Plug and Play for modern Windows OS ( 8, 8.1 , 10 )
• Full Support for legacy OS like Windows XP

**Summary: Improved performance, compatibility, and convenience**

Package include:

• 1 x Easy JTAG Plus Box Main Interface Hardware
• 1 x Z3X Certified EMMC Socket (BGA153/169, BGA162/186, BGA221, BGA529)
• 1 x JTAG Pin 20 Standard Cable.
• 1 x ISP Soldering connector 1bit.
• 1 x ISP Soldering connector 4bit.
• 1 x USB A to B Cable
• 1 x NAND Socket Set
